Frequency inverter
0.25 - 2000 kW
Watt Drive Antriebstechnik GmbH
Drive Electronics
The frequency inverter programs S-line, B-line, E-line and P-line consistently follow the same principle in the range of 0.2 to 90 kW as the Watt Drive modular drive systems.
These frequency inverters distinguish themselves through their excellent control features, compact size, ease of use and very good communication skills.
The differences between the four programs lie primarily in the control features and thus the starting torque and dynamic performance achieved.
The S models are V/F controlled, while the B, E and P range consists of vector-controlled frequency inverters.
The E-line offers implemented EMC filters and brake choppers in series, as well as many possible extensions for the digital and analog in- and outputs. Moreover an integrated SPS control is available.
The P range features distributed intelligence e.g. for positioning tasks. This complete range of modular drive control units offers the technically best and most cost-effective drive solution for any requirement, from simple open loop control to top dynamic closed loop process control and positioning applications.
Watt Drive is able to offer a complete range of modular drive control units and the most cost-effective drive solution for any requirement, from simple control and drive tasks to the control of top dynamic processes and positioning.
