water pressure switch / for air / for steam / diaphragm
LF05 ZHEJIANG LEFOO CONTROLS CO., LTD

{{requestButtons}}

Characteristics

  • Fluid:

    for water, for air, for steam

  • Technology:

    diaphragm

  • Other characteristics:

    compact, stainless steel

  • Process temperature:

    Max.: 125 °C (257 °F)

    Min.: 0 °C (32 °F)

  • Pressure range:

    Max.: 4 bar (58.02 psi)

    Min.: 1.5 bar (21.76 psi)

Description

LF05 is a small size and high performance pressure switch, it has the inner construction of SPST connection and silver contact. The switch can be used in circuit control that the max current can be up to 16A. High qualitystainless steel diaphragmis dedicated to control equipment of high temperature and pressure with water vapor. Compact appearance make this switch suitable for devicesthat havethe smaller internal installation space.
