band sawing machine / for metals / for profiles / automatic
WY360HB Zhejiang Weiye Sawing Machine Co., Ltd

{{requestButtons}}

Characteristics

  • Technology:

    band

  • Treated material:

    for metals

  • Applications:

    for profiles

  • Other characteristics:

    automatic, fully automatic, with cooling system, horizontal, double-column, with hydraulic vise, PLC-controlled, hydraulic

  • Round piece diameter:

    Min.: 20 mm

    Max.: 360 mm

    360

Description

WY360HAS type designed and finished by WEIYE SAWS, suits straight cutting metallic materials with high performance, capacity 360mm of outer diameter and features as follows:

Specification
Capacity:■360H*400W
Blade Speed(m/min) 20~70 belt pulley
Blade Size(mm) 34*1.1
Main drive 4KW

Features
Optimized machine design with main drive adopted worm gear box and belt pulley.
Carbide guide kit for the saw guides to lengthen the service life of blade
Hydraulic indexing 600mm each time, repeatable feed in for long materials.
Adopts linear scale for the measurement, high precision.
Hydraulic workpiece clamping,bundle clamps included.
Hydraulic feed rate and back pressure control through valves, variable blade speed provides by the beltpulley.
Material feed rate display from the touch screen.
Adopts PLC, HMI, console to ensure fully automatic cutting process, with easy and friendly interface.
Hydraulic band tighten
Powered wire brush and chip auger for chip removal, with high efficiency
Safety protection device on request
Safety cover check device enables cover of saw wheels opened shut off
Band check device enables breakage found shut off
Electric cabinet door check device enables door of electric cabinet opened shut off
Main parts adopts famous brand from mainland of China
