Rotational speed: 6,500 rpm - 8,500 rpm
Gripping force: 48 kN - 250 kN
Outer diameter: 110 mm - 315 mm
... jaw power chuck is based on approved KFD-HS. The steel designed chucks offers a distinguished feature of all moving parts permanently lubricated in an oil bath. This makes the KFD-HS ...
Rotational speed: 3,500 rpm - 6,300 rpm
Gripping force: 75, 110, 135, 160 kN
Outer diameter: 315, 170, 210, 254 mm
The KFD-HE series is a unit manufactured by Rohm company. It is a unit intended for lathe and for materials that have large hole fitted for both bar that works. Furthermore, the unit has high radial and axial true-running accuracy and ...
Rotational speed: 1,800 rpm - 3,400 rpm
Gripping force: 24 kN - 66 kN
Outer diameter: 160, 215, 280, 350 mm
The KFG series is manufactured by Rohm, and is a very versatile power chuck that is integrated with a large through-hole, which is highly appropriate for both bar work and chucking the most varied parts. ...
Rotational speed: 3,000 rpm - 55,000 rpm
Outer diameter: 102, 151, 202 mm
... Key highlights of this chuck are the piston's unique design that has force transmission on both sides. Radial and axial true running accuracy is under 0,003 mm (3 micron). It is based on the RÖHM KFD-HS principle. The ...
Rotational speed: 2,000 rpm - 4,000 rpm
Gripping force: 90, 140, 190, 250 kN
Outer diameter: 315, 400, 200, 250 mm
The KFD-EC Series is specifically designed to provide a good quality functionality and performance. It is mainly built to be used fot maximum operation conditions including the dry or raw part machining and high coolant pressure systems. ...
Rotational speed: 1,200 rpm - 5,000 rpm
Gripping force: 12 kN - 360 kN
Outer diameter: 85 mm - 630 mm
The KFD series is manufactured by RÖHM. This model of power chuck is featured with a high load carrying capacity, long life and high work holding accuracy. The operating power is transmitted ...
Rotational speed: 2,200 rpm - 3,500 rpm
Gripping force: 10, 12, 25, 29 kN
Outer diameter: 250, 315, 125, 160, 200 mm
... load carrying capacity, long life and high work holding accuracy. A sturdy wedge system is used in transmitting the operating power. The workpieces can be clamp with collars and shoulders without through-hole. The ...
Rotational speed: 1,700 rpm - 6,300 rpm
Gripping force: 60 kN - 305 kN
Outer diameter: 180 mm - 630 mm
... a range of jaw power chucks that feature a quick-acting jaw change system with individual jaw unlocking. They have straight teeth, and also provide an adaptor recess with the mounting dimensions to DIN ...
Rotational speed: 1,500 rpm - 6,300 rpm
Gripping force: 49 kN - 330 kN
Outer diameter: 145 mm - 630 mm
APPLICATION Standard power chuck with through-hole for flexible use thanks to quick jaw change system. TYPE Power chuck available with cylindrical centre mount. ...
Rotational speed: 1,800 rpm - 4,000 rpm
Gripping force: 20, 35, 60, 95, 120 kN
Outer diameter: 136, 168, 205, 255, 320 mm
RÖHM presents type 525-00 LVE chucks. These chucks are suited for machining flanges and bar stock as well as for chucking pipes. The chuck body includes an actuating cylinder. It does ...
