Helical actuators

Pressure: 10 bar - 250 bar
Force: 1.45 kN - 256.25 kN
Torque: 180 Nm - 250,000 Nm

... datum •angle adjustment ± 5° The reference among the rotary actuators The SM4 is a rotary actuator with an operating pressure up to 250 bar, which works according to the 'helical ...

Pressure: 250 bar
Force: 1,567 N - 34,100 N
Torque: 200 Nm - 6,000 Nm

SPECIFICATIONS Working Pressure up to 250 bar Torque up to 250.000 Nm Angle of Rotation up to 1.080° Special Angle of Rotation up to 1.500° All sliding surfaces are surface-hardened Rotary pistons can be run to their end stop positions ...

DA-H Working pressure 3,650 PSI Torque up to 2,200,000 LBS Angle of rotation up to 360° Special angle of rotation up to 1500° Preferred applications: Industry (construction machinery) DA-H-AL Working pressure 3,000 ...

Pressure: 210 bar
Torque: 250,000 Nm
Rotation angle: 360 °

... on a system with a multiple helical gear. The linear movement of the piston is converted into a rotational movement via the multiple helical gears. The rotational movement will be greater ...

... proven HKS rotary actuator with a double acting linear motion unit has been condensed into a compact module in order to do this. Modules that best meet your needs can be chosen from our two model ranges. DHK-H-ZV Helical ...
