Asymmetric distribution with wide bilateral.
This model is available in two different Protection Classes against electric shock.
Asymmetric distribution with frontal, wide or medium bilateral.
No higher ULOR emission.
Lifetime (L80/B10): 100000 h. (tq+25°C)
Photobiological safety RG0.
SOURCE
Squared LED module with special protection against aggressive chemically‑volatile substances, for standard LED technology.
Colour initial tolerance (MacAdam): SDCM 5.
MECHANICAL
Aerodynamically‑shaped die‑cast aluminium double‑shell body for low wind resistance, equipped with fins to optimize the cooling of the internal components.
Shell closure using stainless steel screws on stainless steel bushings, with hinged opening for easy access to the wiring compartment, equipped with system against accidental closure.
Polyester powder coating with degreasing pre‑treatment and phosphate layer deposit on the metal, UV stabilised, corrosion resistant, anthracite colour, salt spray resistance ISO 9227 >1000 h.
Parabolic cellular optics with total recovery, entirely made of semi‑specular high reflection aluminium with titanium and magnesium surface treatment, to maintain optical performance over time.
Polyurethane foam seals, ecological, anti‑aging, installed using a continuous automatic process with no joints.
VT extra transparent tempered glass diffuser, 4 mm thick, non‑combustible.
Stainless steel internal and external screws.
ELECTRICAL
In compliance with EN 60598‑1, EN 60598‑2‑3.
Flicker: <10%.
Safety break switch to shut off the power supply when opening the device.
Insulation voltage 6kV via Sourge Protector.
