Block lifter ABGL-1800

General
The Brick Grab Lifter is designed to mechanically lift, transport and accurately place bricks and concrete blocks without additional hydraulic or electrical connections. Rubber-covered clamping jaws provide a secure grip on masonry units. The unit is compatible with overhead cranes, mobile cranes, truck-mounted cranes and forklifts, making it suitable for construction sites and manufacturing facilities. It is intended for non-palletized loads and can operate from constrained or awkward positions. The adjustable plunge depth accommodates varying pack heights.

Features

• Fully automatic clamping and release mechanism.
• Adjustable plunge depth for different pack sizes.
• Profiled hooks for secure attachment to slings or crane fittings.
• Designed for handling non-palletized loads in confined spaces.
• Reduces handling time and on-site labour requirements.

Specifications
Metric | Imperial
Grip range: 800 - 1100 mm | 31″ – 43″
Pad length: 1200 mm | 47″
Internal height: 1100 mm | 43″
Working load limit: 1800 kg | 3968 lb
Net weight: 590 kg | 1301 lb
Gross weight: 610 kg | 1345 lb
Packaging dimensions: L.1550 x W.1270 x H.2110 mm | 61″ x 50″ x 83″

Technical specifications

• Grip range: 800 - 1100 mm (31″ – 43″).
• Pad length: 1200 mm (47″).
• Internal height: 1100 mm (43″).
• Working load limit (WLL): 1800 kg (3968 lb).
• Net weight: 590 kg (1301 lb).
• Gross weight: 610 kg (1345 lb).
• Packaging dimensions: L 1550 x W 1270 x H 2110 mm (61″ x 50″ x 83″).
