Concrete placing boom Elba CES series

Overview
The automatic scrapers of the Ammann Elba CES series improve operational efficiency through automation. An operating module provides straightforward programming and control of the scraping sequence. Semi-automatic/manual operation for scraping, retracting and slewing motions is also available.

Key points

• Operating module for programming and process control
• Fully automatic and semi-automatic/manual operation modes (scraping, retracting, slewing)
• Three model families (CES 15, CES 50, CES 70) with multiple boom lengths

Specifications table
Type | Boom length [m] | Max. theoretical scraper output [m³/h]
CES 15 | 12 | 57
CES 15 | 13.5 | 52
CES 15 | 15 | 48
CES 50 | 17.5 | 118
CES 50 | 20 | 108
CES 50 | 22.5 | 99
CES 70 | 17.5 | 155
CES 70 | 20 | 135
CES 70 | 22.5 | 125

Notes
Actual scraper output may be up to 30% lower than the theoretical output depending on overall box angle, fill level, number of boxes and on operational downtime or idle times.

Technical data / characteristics

• Series: Ammann Elba CES series
• Control: Operating module for programming and process control
• Operation modes: Fully automatic and semi-automatic/manual (scraping, retracting, slewing)
• Available boom lengths and theoretical outputs: see specifications table above
• Performance note: actual output may be up to 30% lower depending on operating conditions
