Mechanical tachometer CAP8535

handhelddigitalwith LCD display

Product overview
The CAP8535 universal tachometer, designed by Capelec, measures engine speed (RPM) and temperature for a wide range of vehicles. It combines two measurement modes (battery and vibration) with wireless connectivity and a compact LCD interface for easy integration in inspection and maintenance workflows.

Key features

• Dual measurement modes: battery (BAT) and vibration (VIB)
• Bluetooth wireless connection for data transfer
• LCD display for clear readout
• New-generation 3D vibration sensor
• Long-life lithium battery
• Compatible with light vehicles, heavy goods vehicles and 2-wheelers
• Suitable for petrol and diesel engines

Applications

• Vehicle inspection centres and repair workshops: verification of engine speed and temperature
• Manufacturers and industrial test benches: engine speed and temperature measurement during development and production

Technical specifications

• Function: Tachometer (RPM) and temperature
• Voltage: +9 to +30 VDC
• Battery: Lithium
• Power supply: 100/240 V, 50-60 Hz
• Measurement range: 400 to 9 999 rounds/min; temperature range: -13°C to +150°C
• Measurement accuracy: <+/- 20 RPM from 400 to 2 000 rounds/min; <+/- 2% from 2 001 to 9 999 rounds/min; +/- 1°C
• Resolution: 10 RPM; 1°C
• Initialization time: BAT < 15 seconds; VIB < 10 seconds
• Response time: < 0.5 seconds
• Refresh rate: 0.15 seconds
