planetary mixer / batch / powder / solid
V series

Add to MyDirectIndustry favorites
Compare this product
planetary mixer / batch / powder / solid planetary mixer / batch / powder / solid - V series
{{requestButtons}}

Characteristics

  • Technology:

    planetary

  • Batch/continuous:

    batch

  • Applications:

    powder, solid

  • Application domain:

    for the food industry

  • Other characteristics:

    vertical, compact, mobile, conical

  • Capacity:

    11.5 l, 24 l, 46 l, 110 l, 180 l (3.04 gal)

Description

UNIVERSAL MIXER V 10 – V 200

OPEN DESIGN WITH GEARED MOTOR
The Universal Mixers V 10 – V 200 are designed as especially robust and compact vertical mixers with a cylindrical container that is conical in the top area. A three-winged mixing tool is arranged on the bottom; a chopper is installed on the side. The shafts are equipped with low-wear air gap seals. Emptying takes place on the side through a large discharge valve with a locking piston that lines up precisely with the inner wall. The control via push-buttons and timers is installed in the switch cabinet on the machine.

Areas of application
General: Mixture of solids of all kind also with additions of fluid
Food industry: Spices and herbs mixtures, food for sportsmen, breading, instant beverages, instant soups, sand, wafer, biscuit masses
Pharmaceutical industry: Humid granulations, Powder and granulate mixtures
Chemical/plastics industry: Powder lacquers, master batches,
Cosmetics: Eye shadow, face powder, rouge, dental mixtures

Advantages
Outstanding mixing results
For difficult mixtures suitable
Compact machines
Easy to operate
To be cleaned very well

Options
Mobile design
Controllable speed of the mixing tools
Reinforced drive
PLC control
Feed unit for solid materials and fluids
