Scissor lift table CH
electricelectro-hydarulicmobile

scissor lift table
scissor lift table
scissor lift table
scissor lift table
scissor lift table
scissor lift table
scissor lift table
scissor lift table
scissor lift table
scissor lift table
scissor lift table
scissor lift table
scissor lift table
scissor lift table
scissor lift table
Add to favorites
Compare this product


Characteristics

Technology
scissor
Operation
electric, electro-hydarulic
Type
mobile
Application
loading, for heavy loads, tilting
Other characteristics
custom, high-performance, rotating, precision, with protective bellows, for coils
Capacity

Max.: 20,000 kg
(44,092.5 lb)

20,000 kg
(44,092.5 lb)

Min.: 1,000 kg
(2,204.6 lb)

Lowered height

Max.: 550 mm
(22 in)

350 mm
(14 in)

Min.: 300 mm
(12 in)

Lifting height

Max.: 2,500 mm
(98 in)

650 mm
(26 in)

Min.: 650 mm
(26 in)

Stroke

1,500 mm
(59.06 in)

Tray width

Max.: 2,000 mm
(78.74 in)

800 mm
(31.5 in)

Min.: 800 mm
(31.5 in)

Lift time

Max.: 20 s

10 s

Min.: 6 s

Description

Your partner for coil handling Coil Handling in the installation sector With Dynalserg's coil handling program, manufacturing plants are more profitable! Steel, aluminium, paper or plastic are introduced into or moved with care and safety in the production processes. Dynalserg has an extensive program, whether it is a longitudinal, transverse or even a high-performance machine with additional equipment for drilling, bending or profiling. If the materials are processed from the coil, short changeover times are required at the winding and unwinding stations (up- & uncoiler). For all processes that are related to concatenation or buffering, Dynalserg has high-performance equipment for complex production processes. These equipments are the lift truck and the coil magazine - the devices for rotating, tilting and turning the coils. A team of qualified consultants with many years of experience in the field of special material flow technology ensures that everything is properly integrated from the planning stage.
