Wireless receiver ENRCV00radiodigitalUHF
Add to favorites
Compare this product
Characteristics
- Type
- radio, UHF, wireless, digital, multi-frequency
- Applications
- for remote control, industrial, for construction site, harsh environment, monitoring, automation, telemetry, for UAVs, for robotics, fieldbus, for actuators
- Interface type
- CAN Bus, USB, Ethernet, fieldbus, RS232, RS-485, CANopen, internet, TCP/IP, Profibus, Modbus, ProfiNet
- Other characteristics
- rugged, with relay output, 915 MHz, OEM, CE certified, IP65
Description
Product overview
With the ENRCV00 Series industrial receiver you can control and monitor machine modules that communicate over major industrial bus systems. It acts as the interface between an ExRemote handheld remote and machine controllers, translating operator commands into application-specific control of motors, actuators and automation functions. The ENRCV00 Series is programmable to match your machine logic and control philosophy; ExRemote offers development services to configure receiver logic and integrate it with your system.
Key features
Wireless and connectivity
The receiver implements Listen Before Talk and Channel Hopping to ensure a robust wireless link. In environments with potential self-interference, transmit power can be reduced in the field. Up to four remotes can operate concurrently at the same location, and automatic remote discovery at boot simplifies pairing. Where wireless use is restricted, an optional wired connection is available.
ATEX considerations
The ENRCV00 Series is not ATEX/IECEx or Ex certified. It can, however, be installed inside a pressurized "Ex p" control cabinet to allow use within an explosive atmosphere as part of a compliant system. Use intrinsic safety (IS, "Ex i") barriers for any wired connection toward the remote.
Key specifications
With the ENRCV00 Series industrial receiver you can control and monitor machine modules that communicate over major industrial bus systems. It acts as the interface between an ExRemote handheld remote and machine controllers, translating operator commands into application-specific control of motors, actuators and automation functions. The ENRCV00 Series is programmable to match your machine logic and control philosophy; ExRemote offers development services to configure receiver logic and integrate it with your system.
Key features
- Flexible control and system integration
- Compatible with major industrial bus systems to connect with supported modules
- Programmable behaviour to meet control and safety requirements
- Supports both control and monitoring for feedback and status handling
- ExRemote development service available for implementation and integration support
Wireless and connectivity
The receiver implements Listen Before Talk and Channel Hopping to ensure a robust wireless link. In environments with potential self-interference, transmit power can be reduced in the field. Up to four remotes can operate concurrently at the same location, and automatic remote discovery at boot simplifies pairing. Where wireless use is restricted, an optional wired connection is available.
ATEX considerations
The ENRCV00 Series is not ATEX/IECEx or Ex certified. It can, however, be installed inside a pressurized "Ex p" control cabinet to allow use within an explosive atmosphere as part of a compliant system. Use intrinsic safety (IS, "Ex i") barriers for any wired connection toward the remote.
Key specifications
- I/O: 2 x relay (NO + COM + NC); 3 x DO
- Supported bus systems: Modbus (RS485), CAN (CANopen), ProfiNET (DB) and others on request
- Operating temperature: -20 °C to 60 °C (-4 °F to 140 °F)
- Protection rating: IP65+ (water and dust tight)
- Impact resistance: IK10+
- Power supply: 24 VDC; consumption < 100 mA
- Frequency bands: 868 / 915 / 925 MHz (configurable for worldwide coverage)
- Wireless range: Up to 220 meter (700 feet) line of sight
- Certification: CE
