Mobile scalper screen FTB-1550
heavy-dutywith belt feeder

Mobile scalper screen - FTB-1550 - Fabo Crushing Screening & Concrete Plants - heavy-duty / with belt feeder

Mobile scalper screen - FTB-1550 - Fabo Crushing Screening & Concrete Plants - heavy-duty / with belt feeder - image - 2

Mobile scalper screen - FTB-1550 - Fabo Crushing Screening & Concrete Plants - heavy-duty / with belt feeder - image - 3

Mobile scalper screen - FTB-1550 - Fabo Crushing Screening & Concrete Plants - heavy-duty / with belt feeder - image - 4

Mobile scalper screen - FTB-1550 - Fabo Crushing Screening & Concrete Plants - heavy-duty / with belt feeder - image - 5

Mobile scalper screen - FTB-1550 - Fabo Crushing Screening & Concrete Plants - heavy-duty / with belt feeder - image - 6

Mobile scalper screen - FTB-1550 - Fabo Crushing Screening & Concrete Plants - heavy-duty / with belt feeder - image - 7

Mobile scalper screen - FTB-1550 - Fabo Crushing Screening & Concrete Plants - heavy-duty / with belt feeder - image - 8

Mobile scalper screen - FTB-1550 - Fabo Crushing Screening & Concrete Plants - heavy-duty / with belt feeder - image - 9

Add to favorites

Compare this product

Go to the Fabo Crushing Screening & Concrete Plants website for more information

Characteristics

Type

mobile

Other characteristics

heavy-duty, with belt feeder

Weight

32,000 kg
(70,548 lb)

Capacity

Max.: 400 t/h
(245 lb/s)

Min.: 220 t/h
(135 lb/s)

Engine power

110 kVA
(149.56 hp)

Description

FABO Mobile Scalper screen is produced for aggregate producers who require higher productivity and versatility. The machine can be used for multiple purposes; it can be used as a heavy-duty incline 2 deck screen, capable of stockpiling, scalping before and after crushing units, or it can be used a standalone system as well. That is why FABO tracked mobile scalpers can separate the hardest materials. FABO Mobile Scalpers helps our customers to maximize productivity while on the other hand helps on reducing the production costs. - - - - - - Technical Specifications of the Tracked Scalper Screen: - - *Bunker capacity :7m³ - - *Production capacity - - : 220 – 400 Tons per hour - - *Vibrating Screen Size - : 1530x4800 mm - - *Total Power - - - : 110 kvA - - *Weight - - - : 31.000 kg - - *The screen angle varies between 18-27°.
