RFID reader-writer with PC interface FD-135-001

» Dimensions: 174mmx134mmx54mm » Easy installation: » Wide power supply range: 12/24 Vdc or Vac. 1A, reader and receiver: 2 polarised wires 100m max, removable terminal connections, setting on the controller via display and three buttons » 5000 keys or remote control per controller / 6500 per site » 2 or 4 doors per controller depending on model/128 doors per site Advanced functions: » Free access to door depending on time » Anti pass back / anti pass time management » Events management (30000 last events) » Management of FDI's entry panel » Keys management via software + encoder » Removable back-up memory ■ Vigik approved product The read and write system is suitable for property managers wishing to manage the access control of their remote buildings without having a connection with these buildings. At the office, Visopac user creates access profiles and encode the keys. When these keys are presented to the readers, the controller authorizes or not the acess and updates its own database. Thus, controllers are always up to datewithout communicating directly with the Visiopac server. This system also provides a very accomplished key management as it possible to authorize a key to thousands of doors, assign validity dates or schedules. Vitwois able to manage FDI's entry panels. In this case, authorization ok keys and names, call codes and / or combined are updated on the display when the card is presented for the first time. On the other hand, the user of Vitwo only needs to manage access control and intercom.
