Holes can be Round (R), Square (S), Hex (H), Oblong (LR), Rectangular (LC) or diamond (CD)
Perforation layout is defined by letters T -U- Z- M according to the arrangement of holes in relation to one another.
Applicable standards
NFE 81061
NFE 81063
Perforation
Hole dimensions vary from 0.5mm to 50mm.
Thickness
Depending on hole thickness of material can be from
0.08mm to 15mm.
ACIER
Cold rolled steel
DC01
Standard
NF EN 10130
Recommendations
To avoid risk of corrosion, we
recommend applying an anticorrosion surface treatment for
relevant to your application.
Hot rolled steel
S235JR - DD11
Standard
NF EN 10025-2 (S235JR)
NF EN 10111 (DD11)
Recommendations
To avoid risk of corrosion, we
recommend applying an anticorrosion surface treatment for
relevant to your application.
The material is suitable for hot-dip
galvanising.
Steel galvanised before cutting
DX 51D + Z140 or Z275
Standard
NF EN 10327
Recommendations
To avoid risk of corrosion, we
recommend applying an anticorrosion surface treatment for
relevant to your application.
