Zinc-iron zinc-plating
ISO 9001ISO/TS 16949

zinc-iron zinc-plating
zinc-iron zinc-plating
zinc-iron zinc-plating
zinc-iron zinc-plating
zinc-iron zinc-plating
Add to favorites
Compare this product


Characteristics

Type
zinc-iron
Certifications
ISO 9001, ISO/TS 16949

Description

Features The Zinc Iron process is applied in a (bass) drum and (static) frame system in transparent and black finishes free of Cr VI, when the requirements demand high-resistance protection from corrosion and an attractive aesthetic appearance. The system consists of a metal deposition in an alkaline electrolyte of Zinc Iron with a contribution of 0.5 % to 0.7 % of Fe; subsequently, the transparent or black passivation protects the Zinc Iron coating from white corrosion of iron and an additional seal (Top Coat) that penetrates in the passivation ends up closing its micro-cracks and pores. The Top Coats applied are perfectly adapted to the prior passivations and, besides raising corrosion protection, they improve the aesthetic appearance and increase the surface hardness of the coating. The coefficient of friction for the fixing elements may be modified in accordance with the International Standards of the automotive industry. They have good ductility for possible subsequent mechanical operations. The adhesion of epoxy paints or thread applications is excellent on all passivations, mainly Black ones (Without Top Coat Seals) “The distribution and penetration into the interior of the workpiece is pretty good Respects European Directive 2003/EC/53 and RoHS.”
