Fiber laser marking machine S6-F

CO2 lasermetalbarcode

* Fully automatic control, PC+QC software control, Windows 10 operating system. * Optional CO2/FB/UV/GR laser marking system, with XY precise platform, CCD+MARK precise positioning. Accuracy of marking position within 0.02mm. (here use Fiber) * Can print Chinese characters, English, numbers, charts, serial numbers, LOGO, barcodes, two-dimensional code and so on. * Can access shopfloor\MES system. * Support Gerber,DXF and other documents import. * Support marking various types of PCB, FPC, non-metal and other different material surface. * with high quality, high yield, high stability, no production supplies, etc. — Characteristics of software operation * Visual operation of the edit template is displayed on the PCB board in real time, so editors can adjust the size, text position, text spacing, etc. via viewing marking area. User friendly operation. Quick operation to adapt to various bar code rules, and around 3minutes needed to edit a template. * CCD visual operation be used for all editing action, simple and convenient. * It’s equipped with function of anti-remarking data to avoid repeat marking of barcode information. * Array function be equipped with barcode marking, simple and quick. And it’s convenient to mark barcode of multilink PCB or a PCB with variety specifications. * Barcode can be dragged to any position in the PCB board, and also can mark current position which move to in real-time, no need survey coordinate. Drag the barcode identifier to the corresponding position to modify the data instead of changing the coordinate data, intuitive operation. ● 0.8mm minimum size of the barcode ● Self-developed marking software
