Multi-function utility vehicle Multicar M41

dieseldump bed4-wheel drive

Overview
The Multicar M41 is a compact, highly manoeuvrable 7.5‑ton class municipal load and implement carrier engineered for year‑round municipal and special applications. It pairs a power‑split transmission—hydrostatic at low speed and mechanical at higher speed—with permanent all‑wheel drive to deliver traction, comfort and fuel efficiency.

Key features

• Power‑split transmission enabling hydrostatic drive at low speeds and efficient mechanical drive at higher speeds
• Permanent 4x4 drive with optional all‑wheel steering for improved traction and manoeuvrability
• Three‑way tipper with large loading bed configurable for unloading in any direction
• Ergonomically optimised cab with joystick control and a clear, easily accessible control panel and colour multifunction display
• Electric parking brake with automatic activation and hill‑hold function for operator comfort and safety
• Versatile interfaces and attachment options for year‑round municipal tasks and specialist equipment

Applications / Multifunctionality

• Green area maintenance (mowing, cutter bars, flail and rotary mowers, boom mowers, mower‑suction combinations)
• Sweeping and suction sweeping operations
• Transport and construction site work (three‑way tipper, skip loader, combinations with loading crane or grapple)
• Waste management and disposal tasks
• Winter service with snow ploughs or brushes
• Cleaning, irrigation and transport of waterjet / high‑pressure cleaning units

Technical specifications

• Engine: Diesel, 129 kW (175 hp)
• Traction drive: 4x4 permanent all‑wheel drive; hydrostatic‑mechanical power‑split transmission, infinitely variable; top speed 0–90 km/h
• Dimensions (L x W x H): 4,840 x 1,750 x 2,395 mm
• GVW / Maximum payload: 7,490 kg / 4,250 kg
• Suspension: Coil springs with additional rubber springs
• Gradeability: approx. 45% at 7.49 t GVW; up to approx. 100% unladen (manufacturer data)
• Cab & controls: Ergonomically optimised workplace, joystick control, colour multifunction display
• Safety/comfort: Electric parking brake with automatic activation and hill‑hold function
• Emissions: Engine complies with Euro VI‑E emission limits; exhaust aftertreatment active in all operating states
