Single-phase motor NCJ / NLJ
asynchronous230 V115 V

single-phase motor
single-phase motor
single-phase motor
Add to favorites
Compare this product

Go to the Huifeng Motors website for more information

Characteristics

AC/DC
single-phase
Type
asynchronous
Voltage
230 V, 115 V
Protection class
IP54, IP43
Configuration
squirrel cage, squirrel-cage rotor, with run and start capacitors, with start capacitor, with start capacitor and relay, TENV, removable legs, vertical, with 2 capacitors, with 1 capacitor
Number of poles
4-pole
Cooling mechanism
self-ventilated
Applications
for boat, for lifting applications, for marine applications
Other characteristics
low-voltage, custom, high-efficiency, high-torque, low-noise, high-power, low-vibration, NEMA, energy-saving
Power

Max.: 1.5 kW
(2.039 hp)

Min.: 0.37 kW
(0.503 hp)

Rotational speed

1,800 rpm
(11,309.73 rad.min-1)

Operating temperature

Max.: 40 °C
(104 °F)

Min.: -10 °C
(14 °F)

Description

The motor is designed for boat lift that requires S2-15min duty running. The boat lift motor is for Direct Drive Units, it’s designed for the motor shaft to go directly into the gearbox, it’s not compatible with Flat Plate Gear Units, it means it can not work with hoist that use a belt and a pulley. •Motor enclosure: Totally Enclosed Non Ventilated (TENV) •Suitable for S2-15min duty •1.15 Service Factor (1.0 SF @ 50Hz) •Rigid Base (Welded on), or C-Face with Removable Feet or Round Body (Footless) are Optional •T Flange and Customized Shaft End is Available •Steel Frame and Junction Box •Aluminum or Cast Iron End Bracket for Alternative •Insulation Class F, Temperature Rise Class B •Manual or Automatic Overload Thermal Protector is Available
