Infrared sensor module H08R6x

H08R6x is an infrared (IR) time-of-flight (ToF) ranging sensor module based on ST VL53L0X sensor and STM32F0 MCU. This sensor is immune to surface reflectance or varying lighting conditions and can function as a 1D Lidar or gesture-detection interface. It can measure distance accurately up to 2m. Lidar IR Sensor board pcba(H08R6x) Feature and Parameter: Technical Specifications * Use this module as a stand-alone, accurate ranging device for robotics and automation applications. * Combine with other H08R6 or P08R6 modules to create arrays of geometrically-distributed Lidar sensors. * Use as gesture-detection/input device and combine in arrays to detect a wider range of motion. * Program advanced C code with our easy-to-use APIs. * Connect to external hardware or combine with other Hexabitz modules! Front-End *ST VL53L0X Time-of-Flight (ToF) ranging and gesture detection sensor: * 940nm Laser VCSEL. * Eye safe Class I laser. * Measures absolute range up to 2m. * Reported range is independent of the target reflectance. Back-End * STM32F091CBU6 32-bit ARM Cortex-M0 MCU. * 8MHz external oscillator. * Six array ports and six power ports (+3.3V and GND). * Access to 6xUART, 2xI2C, SWD, BOOT0, RESET.
