Shock data logger S5-E100D40

humiditylight-intensityvibration

Overview
The S5-E100D40 is a handheld vibration and shock recorder by enDAQ combining a high-performance piezoelectric primary accelerometer with a digital capacitive secondary accelerometer and multiple embedded environmental sensors. The aluminum 7075 enclosure extends durability and frequency response for industrial data collection.

Key specifications

• Model: S5-E100D40
• Primary accelerometer: Piezoelectric ±100g, up to 20,000 Hz
• Secondary accelerometer: Digital capacitive ±40g, up to 4,000 Hz
• Battery: 850 mAh (rechargeable)
• Storage: 8 GB onboard
• Mass: 100 g
• Ingress protection: IP50

Product Features
Convenient:

• Standalone measurement system with sensors, onboard storage and rechargeable battery
• Handheld form factor for field use
• Quick setup via USB interface

Adaptable:

• Dual accelerometers to cover wide dynamic range
• Multiple embedded sensors in a single unit
• User-programmable wake-up conditions and sample rates

Reliable:

• Designed for harsh environments; aluminum 7075 case
• Calibrated with NIST-traceable accelerometer; certificate available
• Storage capacity suitable for large datasets

Accelerometer Specifications

• Piezoelectric: Range ±100g — Sampling up to 20,000 Hz — Bandwidth ~5–2,000 Hz — Noise <0.04 gRMS — Resolution <0.005 g
• Digital capacitive: Range ±40g — Sampling up to 4,000 Hz — Bandwidth 0–300 Hz — Noise <0.01 gRMS — Resolution 0.00008 g

Additional Sensor Specifications

• Microphone: up to 20,000 Hz
• GPS location: ~2.5 m accuracy, up to 1 Hz
• GPS time: 60 ns resolution
• Gyroscope: 2000 °/s, sampling to 3,200 Hz
• Magnetometer: ±1300 µT, resolution 0.3 µT
• Temperature: -40 to 85 °C, resolution 0.01 °C
• Pressure: 1 to 200 kPa, resolution 1.6 Pa
• Humidity: 0–100 %RH, resolution 0.04 %RH
• Light: <100 mlx sensitivity, sampling to 4 Hz

Environmental Specifications

• Operating temperature: -20 °C to 60 °C (recharge 10 °C to 45 °C)
• Storage temperature: -20 °C to 25 °C
• Humidity: 0 to 95 %RH (non-condensing)
• Absolute pressure: 20 kPa to 110 kPa
• Shock limit: >3,000 g

Battery & Storage Performance

• Battery: 850 mAh (runtime varies with configuration, rates and temperature)
• Storage: 8 GB onboard
• Examples (approx., room temp): 100 Hz → 22 days storage / 44 h continuous; 1,000 Hz → 9 days / 41 h; 5,000 Hz → 3 days / 30 h; 20,000 Hz → 17 h / 17 h

Dimensions & Mechanical

• Mass: 100 g
• Case: Aluminum 7075
• Dimensions: 76.2 mm × 47.0 mm × 18.3 mm
• Mounting: 4-40 screw or 3M 950 double-sided tape
• Ingress protection: IP50

Free Software & Tools

• Included configuration and analysis software: sensor setup, basic reporting, multi-channel viewing, snapshots and batch export
• Cloud upload for advanced reports and conversion tools

Technical specifications

• Model: S5-E100D40
• Brand: enDAQ
• Primary accelerometer: Piezoelectric ±100g
• Secondary accelerometer: Digital capacitive ±40g
• Battery: 850 mAh (rechargeable)
• Storage: 8 GB onboard
• Mass & Dimensions: 100 g — 76.2 × 47.0 × 18.3 mm
• Operating temperature: -20 °C to 60 °C
• Shock limit: >3,000 g
