Helical gear gear-motor ACcoaxialsolid-shaft
Add to favorites
Compare this product
Characteristics
- Motor type
- AC
- Type
- helical gear
- Shaft orientation
- coaxial
- Shaft configuration
- solid-shaft
- Power
- 50 kW...100 kW
- Torque
- 20 - 50 Nm, 50 - 100 Nm, 100 - 200 Nm, 200 - 500 Nm, 500 - 1000 Nm, 1 - 2 kNm, 2 - 5 kNm, > 10 kNm, 5 - 10 kNm
- Mounting
- flange-mounted, foot-mounted
- Number of stages
- three-stage, single-stage
- Performance
- high-efficiency, high-power
- Product applications
- for conveyor
- Gear ratio
Min.: 1.29 unit
Max.: 328 unit
Description
Helical geared motors reach high gear ratios thanks to shank pinion. They provide very economic performance as well as they are high energy efficient (efficiencies 98% per stage). Available as well in high power range. They are offered with one, two or three stages in foot and flange-mounting version with solid shaft. Innomotics helical geared motors among others find the application in conveyor belts, when transporting packaged goods and in vertical conveyors.
