Locking nut AN15 JP M

steelthreadedmetric

Product name
Locknut AN15 JP M 75x2 — Ø98×13 mm

Description
Locknuts, retaining sleeves and locking plates are commonly used to simplify mounting of bearings on a shaft. These components facilitate installation and axial positioning of bearings and help secure bearing assemblies during operation and maintenance.

Features & benefits:

• Manufactured to JIS dimensions so they are compatible with retaining sleeves, pull-off sleeves and shafts.
• Circlips (retaining rings) are suitable for bearings with bore diameter series 40 or smaller.
• Locknuts are suitable for bearings with bore diameter series 44 or larger.

Country of manufacture
JP (Japan)

Technical information

• Inner diameter = d M75x2 mm
• Outer diameter = D 98 mm
• Width = B 13 mm
• Weight = 0.322 kg

Properties

• Number of rolling element rows: single-row
• Rolling element material: bearing steel
• Cage material: pressed steel cage

Specifications

• Model: AN15 JP
• Inner diameter: M75x2 mm
• Outer diameter: 98 mm
• Width: 13 mm
• Weight: 0.322 kg
• Number of rows: single-row
• Rolling element material: bearing steel
• Cage: pressed steel cage
