Differential pressure transmitter LFM108sensitive element4-20 mA0-10 V
Add to favorites
Compare this product
Characteristics
- Pressure type
- differential
- Technology
- sensitive element
- Output
- 4-20 mA, 0-10 V, RS-485
- Electrical connection
- M16 conector
- Supply voltage
- 24VDC, 12VDC, 8VDC
- Mounting
- wall-mounted
- Fluid
- for air
- Material
- plastic
- Protection level
- IP54
- Applications
- for HVAC systems
- Other characteristics
- low pressure, with LCD display
- Pressure range
Max.: 10,000 Pa
(1.45 psi)Min.: -10,000 Pa
(-1.45 psi)- Precision
1 %
- Long-term stability
0.1 %, 0.2 %
- Process temperature
Max.: 70 °C
(158 °F)Min.: -20 °C
(-4 °F)
Description
Low differential pressure transmitters and low cost pressure sensor controller of LEFOO pressure control have a wide application for air-conditioning/ventilation, duct static pressure measurement, filter and flap control, airflow control, cleanroom control, Lab/Fume hood control, airflow control, VAV and fan control, smoke hood control, furnace airflow control, oven pressurization, fluid, level monitoring, Isolation rooms monitoring, environmental protection, air blower, air cleaning or pneumatic feed lines. energy management systems.
The low differential pressure transducer is ideal for the application of monitoring the vacuum pressure, a gauge pressure of air with differential pressure, such as natural gas, and especially low pressure of non-corrosive gases.
Low Differential Pressure Transmitter LFM108 Features:
* Adopt micro-pressure core, sensitive pressure response
*Digital pressure acquisition and temperature compensation
*Strong stability and long service life
*Measure the precise pressure and flow required for building pressurization and airflow control
