Smart camera IPS 248i FIX-M3-102-I3

digitalindustrialmonitoring

Application - Single compartment depth Software functions - Compartment fine positioning Working range - 100 ... 600 mm Light source - LED, Infrared Camera resolution, horizontal - 1,280 px Camera resolution, vertical - 960 px Marker size (round) - 5 ... 20 mm Reproducibility (1 sigma) - 0.1 mm, depending on the application Supply voltage UB - 18 ... 30 V, DC Number of digital switching inputs - 3 Piece(s) Number of digital switching outputs - 5 Piece(s) Type - Ethernet, PROFINET Function - Process Conformance class - B Protocol - PROFINET RT Transmission speed - 100 Mbit/s Type - Ethernet Number of connections - 2 Piece(s) Type of connection - Connector Thread size - M12 No. of pins - 12 -pin Encoding - A-coded Type of connection - Connector Thread size - M12 No. of pins - 4 -pin Encoding - D-coded Dimension (W x H x L) - 43 mm x 61 mm x 44 mm Housing material - Metal Plastic Lens cover material - Plastic Net weight - 120 g Type of display - LED Operational controls - Button(s) Ambient temperature, operation - 0 ... 45 °C Ambient temperature, storage - -20 ... 70 °C Relative humidity (non-condensing) - 90 % Degree of protection - IP 65 Approvals - c UL US
