5-axis CNC milling machine KX60 Five2verticalwith moving tablefixed-bed
Add to favorites
Compare this product
Characteristics
- Number of axes
- 5-axis
- Spindle orientation
- vertical
- Structure
- with fixed portal, fixed-bed, with moving table
- Spindle mount
- HSK-63-A
- Number of tool stations
- 24 tools
- Applications
- for the mold industry, for automatic tool changers, for matrices
- Other characteristics
- high-speed, high-precision, high-performance
- X travel
4,300 mm
(169 in)- Y travel
2,560 mm
(101 in)- Z travel
1,000 mm
(39 in)- Rotational speed
18,000 rpm
(113,097 rad.min-1)- Power
17.5 kW, 18 kW, 23 kW
(23.79 hp, 24.47 hp, 31.27 hp)- Work feed X-axis
30,000 mm/min
(20 in/s)- Work feed Y-axis
30,000 mm/min
(20 in/s)- Work feed Z-axis
30,000 mm/min
(20 in/s)- Tool weight (max)
5 kg
(11 lb)- Tool-changing time
8 s
- Weight
27,000 kg
(59,524.81 lb)- Overall length
11,150 mm
(439 in)- Overall width
4,370 mm
(172 in)- Overall height
472 mm
(18.6 in)
Description
The portal structure of the machine (mobile table, fixed bed, portal and traverse) enables increased stability and rigidity which are enhanced by controlled thermal stabilization.The “X”, “Y” and “Z” axis are equipped with SCHNEEBERGER roller guides which ensure high accuracy in the positioning of the axes
The HEIDENHAIN pack including a CN IT 530 HSCI, absolute linear encoders, motors for axis and variators enables high speeds and excellent cutting accuracy in roughing and in finishing thanks to the perfect interaction between HSM algorithm of the digital control and different machine parts. The combination of each elements of this machine provides high performance.
This new “KX” range was developed in close cooperation with our clients and our partners in order to meet machining requirements in the field of tool making (mold design, matrices and models), production of parts for aviation and car industry as well as for high precision mechanics products.
