CNC drilling and milling machine LC-1200HS verticalhorizontal3-axis
Add to favorites
Compare this product
Characteristics
- Type
- CNC
- Structure
- vertical, horizontal
- Number of axes
- 3-axis
- Applications
- deep hole
- Number of spindles
- 4-spindle
- Drilling diameter
Min.: 15 mm
(0.59 in)Max.: 40 mm
(1.57 in)- Rotational speed
Min.: 500 rpm
(3,141.6 rad.min-1)Max.: 2,000 rpm
(12,566.4 rad.min-1)
Description
Simultaneous double sides milling + center drilling for vehicle, motorcycle, vessel and agricultural machinery's engine, crank axle, motor spindle parts etc.
Standard accessories：
1.Tool box
2.Hydraulic vise 1 set
3.Central lubrication system
4.Cooling water system
5.Level block & ground bolt
6.Operation manual
Optional accessories：
1.Milling cutter head
2.Milling cutter blade
3.NT50/BT50 collet chuck set
4.Central dril
5.Motor frequency converter (adjust spindle speed)
6.Safety guard
7.Chamfer cutter set
8.Auto feed devicel
Bilaterial milling+drilling(Turing OD, Chamfer) Simultaneous double side face milling + center drilling(chamfer) Ø25mm/dia (30 sec./pc).
