Communication gateway DTA 1600

WANSFPUSB

Overview
DTA 1600 is a compact desktop uCPE gateway powered by the MediaTek® MT7988A quad-core processor. It combines high-speed uplink interfaces and integrated switch ports in a fanless, space-saving enclosure suited to small offices, retail branches and edge locations. The platform supports deployment as a secure branch gateway with firewall and VPN functions or as a uCPE for SD-WAN and virtualized network services.

Main Features

• MediaTek® MT7988A processor, 4-core, 6.3W
• Onboard DDR4 memory, default 4GB
• eMMC 32GB onboard storage
• 1 × 10GbE SFP+ port
• 1 × 2.5GbE RJ45 port
• 4 × 1GbE RJ45 switch ports
• 1 × USB 3.2 Type-A
• TPM 2.0 onboard
• Fanless design, desktop form factor

Product Description
The DTA 1600 leverages the MediaTek® MT7988A (Arm Cortex‑A73 cores) to deliver high packet-processing performance with efficient power consumption. Its interface mix—10GbE SFP+, 2.5GbE RJ45 and four 1GbE switch ports—enables flexible WAN/LAN topologies, high-speed uplinks and segmented local networks. The fanless desktop chassis simplifies deployment where rack space is unavailable. The device can run virtualized network functions as a uCPE for SD‑WAN or provide firewall, VPN and gateway services for secure branch connectivity.

Technical Specifications

• Processor: MediaTek® MT7988A, 4× Arm Cortex‑A73
• Processor power: 6.3W
• Compute: up to ~30K DMIPS
• Memory: Onboard DDR4, default 4GB
• Storage: eMMC 32GB onboard
• Network interfaces: 1×10GbE SFP+; 1×2.5GbE RJ45; 4×1GbE RJ45 (switch)
• USB: 1×USB 3.2 Type-A
• Security: TPM 2.0 onboard
• Design: Fanless desktop form factor
• Intended use: uCPE for SD‑WAN and virtualized network services; secure branch gateway; firewall; VPN router
