Gasoline engine power generator TRT 10three-phaseportable50 Hz
Add to favorites
Compare this product
Characteristics
- Motor type
- gasoline engine
- Phase
- three-phase
- Portability
- portable
- Frequency
- 50 Hz
- Cooling system
- air-cooled
- Applications
- industrial
- Power in kVA
8 kVA
(10.88 hp)- Voltage
400 V
- Length
740 mm
(29 in)- Width
550 mm
(22 in)- Height
520 mm
(20.47 in)- Weight
76 kg
(167.55 lb)
Description
Technical specifications #TRT 10
General parameters
Generator type
Three-phase
Regulation type
Compound
Operational parameters
Weight
76
kg
Electric power 3p/1p
10,0 / 4,0
kVA
Voltage 3p/1p
400 / 230
V
Current 3p/1p
14,2 / 17,0
A
Frequency
50
Hz
No. of sockets
2 x 230 / 1 x 400
V
IP rating
IP 23
Engine
Electric start
No
Maker and typeMaker and type
Honda
GX 390
Fuel
Petrol
Net power
8,7
kW
Emission stage
EU Stage V
Dimensions
Length
740
mm
Width
550
mm
Height
520
mm
