5-axis machining center UNIKAverticalfor steelfor aluminum
Add to favorites
Compare this product
Characteristics
- Number of axes
- 5-axis
- Spindle orientation
- vertical
- Machined material
- for steel, for aluminum, for aluminum alloys, for titanium alloys, for light alloys, for stainless steel
- Structure
- traveling-column, with rotary tilting table, rotating table
- Spindle mount
- HSK-63-A
- Associated functions
- milling, turning
- Applications
- for the aerospace industry, for aeronautics, for the aeronautical industry, for titanium, for turbine blades, for blisk
- Other characteristics
- high-speed, high-performance, high-productivity, high feed rate, compact, high-precision, high-rigidity, with linear motor, with automatic tool changer
- X travel
Max.: 2,000 mm
(78.74 in)Min.: 600 mm
(23.62 in)- Y travel
Max.: 800 mm
(31.5 in)Min.: 300 mm
(11.81 in)- Z travel
Max.: 800 mm
(31.5 in)Min.: 450 mm
(17.72 in)- Rotational speed
Max.: 20,000 rpm
(125,664 rad.min-1)Min.: 0 rpm
(0 rad.min-1)- Power
Max.: 55 kW
(74.78 hp)Min.: 0 kW
(0 hp)- Work feed X-axis
Max.: 60,000 mm/min
(39.37 in/s)Min.: 0 mm/min
(0 in/s)- Work feed Y-axis
Max.: 60,000 mm/min
(39.37 in/s)Min.: 0 mm/min
(0 in/s)- Work feed Z-axis
Max.: 60,000 mm/min
(39.37 in/s)Min.: 0 mm/min
(0 in/s)
Description
High-speed moving column machining centre with box-in-box structure and linear motors for blade and blisk machining
UNIKA is the high-speed machining centre with moving column, one or two rotary tables with direct drive torque motors, designed for extremely high-accuracy blade and blisk machining in aerospace, power generation and turbomachinery sectors.
It ensures a perfect match between rigidity, high-dynamic and geometrical stability (also during 5-axis machining on hard-to-cut materials like titan and superalloys) thanks to its box-in-box structure and linear motors on all axes making it unique worldwide.
Thanks to its advanced structure, UNIKA allows to efficiently face both high-speed roughing and extreme aerodynamic profiles finishing, with the maximum control on surface quality and tolerances.
UNIKA is the Gruppo Parpas technological answer to advanced production of complex components where reliability, repeatability and high-speed makes the difference.
UNIKA is the high-speed machining centre with moving column, one or two rotary tables with direct drive torque motors, designed for extremely high-accuracy blade and blisk machining in aerospace, power generation and turbomachinery sectors.
It ensures a perfect match between rigidity, high-dynamic and geometrical stability (also during 5-axis machining on hard-to-cut materials like titan and superalloys) thanks to its box-in-box structure and linear motors on all axes making it unique worldwide.
Thanks to its advanced structure, UNIKA allows to efficiently face both high-speed roughing and extreme aerodynamic profiles finishing, with the maximum control on surface quality and tolerances.
UNIKA is the Gruppo Parpas technological answer to advanced production of complex components where reliability, repeatability and high-speed makes the difference.
