Automatic plasma marking unit PEDB-C800

high-performancehigh-precision

Product overview
The CO2 laser marking machine PEDB-C800 by Perfect Laser is designed for contact-free marking, engraving and cutting of non-metal substrates including leather, fabrics, wood, bamboo, paper, acrylic and stone. It supports large-area processing up to 800×800 mm and power options of 250W or 350W.

Machine introduction
This CO2 system uses thermal laser-material interaction to remove or modify material without contact. It is engineered for high-precision hollow engraving and can be fitted with an optional CCD vision positioning module for rapid, repeatable alignment. The machine supports hollow cutting, surface etching, grayscale engraving, line marking and dot marking, with stable operation suitable for series production environments.

Key features

• High-speed processing: galvanometer scanning system with marking speeds up to 10,000 mm/s for high-throughput applications.
• Large working area: processing range up to 800×800 mm (customizable) for large-format parts.
• Stable output: fully sealed optical path and imported RF CO2 laser source with long life expectancy (20,000+ hours) and multiple protection measures.
• Constant-temperature cooling: circulation water cooling with multi-layer protection enabling continuous 24-hour operation.
• Integrated control software: compatible with CAD/AI/PLT/ DXF/BMP/JPG, direct TTF font use; automatic layout for text, graphics, barcodes, QR codes and serial numbers.
• Compact industrial design: space-efficient footprint with enhanced exhaust and dust collection provisions.
• Precise adjustment: electric height adjustment and fine 3D focus tuning via micrometer for repeatable accuracy.
• Operator-friendly: intuitive controls for fast operator training and straightforward daily use.

Applications

• Applicable industries: paper products, apparel, leather goods, wood processing, handicrafts, packaging films, stone engraving and related sectors.
• Applicable materials: leather; textiles/fabrics; wood and bamboo; paper and lettering film; adhesive labels; acrylic and other organic/non-metal materials; stone.

Product comparison (summary)

• Marking speed: up to 10,000 mm/s (PEDB-C800) vs ≤7,000 mm/s for many standard models.
• Output uniformity: improved large spot uniformity and stable control for consistent engraving quality.
• Processing quality: cleaner cutting edges, less residue and sharper small characters compared with ordinary lasers.

Packaging & delivery

• Minimum order quantity: 1 unit.
• Packaging: sea-worthy packaging or air-worthy packaging as required.
• Lead time: typically 7–10 working days.
• Payment terms: L/C, T/T.
• Supply capacity: 200 units per year.

Technical specifications

• Brand name: Perfect Laser
• Model number: PEDB-C800
• Product name: CO2 laser marking machine
• Laser wavelength: 10.6 μm
• Laser power: 250W / 350W
• Laser repetition frequency: 1 kHz – 100 kHz
• Marking area: ≤800×800 mm (customizable)
• Marking speed: ≤10,000 mm/s
• Minimum line width: 0.17 mm
• Repetition accuracy: ±0.01 mm
• Cooling method: circulation water cooling (constant-temperature)
• Power supply: AC220V / AC380V, 50Hz/60Hz
• Total power consumption: 7 KVA (250W) / 9 KVA (350W)
• Machine dimensions: 1.68×1.53×1.93 m (250W) / 1.77×1.53×1.93 m (350W)
• Machine weight: 470 kg (250W) / 500 kg (350W)
• Place of origin: China
• Certification: CE
