Oxygen analyzer OXY-FLEX

monitoringconcentrationcompact

0.1% to 25% or 0.1% to 100% oxygen transmitter 4-20mA/0-10VDC and digital outputs selectable Cycling 3.3 V DC logic output allows direct monitoring of the O2 sensor for diagnostic purposes Can be calibrated in normal air, 20.7 % O2, or in any other known O2 concentration Selectable output filtering allows fast and dynamic or slow and stable output Externally triggered automatic or manual calibration Measures in temperatures up to 400degC/750degF Certified CE, UKCA, ISO9001 A compact and cost-effective zirconia oxygen transmitter to measure percentage level oxygen in combustion processes, excess air monitoring, bakery ovens, and many more applications. The unit is configurable to measure either 0-25 % or 0-100 % oxygen and offers manual or automatic calibration to suit the customer’s needs. The probe can be mounted directly on a stainless steel or aluminum electronic housing, and the OXY-FLEX Series is easy to install and integrate into existing systems as no specialist software is required. Typical applications include; combustion control of industrial boilers, burning oil, gas, coal or biomass; composting probes and duct monitoring systems. Suitable Applications Compressed air Class 1 to Class 6 dryers Carbon capture application Inert and bulk gases Optimization of Combustion plants Duct monitoring on HVAC (Heating, ventilation and Air Conditioning) Pharmaceutical Oxygen Control Oil, Gas and Biomass Boilers Composting Commercial baking ovens Oxygen generation
