Binary Gas Analyzer - LDetek LD8000-TCD
Thermal Conductivity-Based Gas Monitoring
Features
- Unique Thermal Conductivity Detector (TCD)
- Bootloader integrated for software update via Ethernet
- Large scale measurement
- 4-20 mA output as standard
- Range Identification Relay
- Maintenance free
- LAN/Web control
- Micro-valve for very low dead volume and fast purging time
- 3U cabinet
The LD8000-TCD analyzer offers direct and continuous measurements of a gas component in a binary gas mixture. It is a compact, rack-mountable unit for industrial & laboratory use. It uses a Thermal Conductivity Detector (TCD) enabling measurements in the ppm to % measurements for binary gas mixtures.
Measurements of one component in more complex gas mixtures is also achievable when the background gases have the same ratio to each other or have similar thermal conductivity values.
The larger the difference between the thermal conductivity of the gas of interest and the background gas(es), the lower the limit of detection. For this reason, each application will different measurement ranges.
SPECIFICATION
DETECTOR TYPE :
Thermal Conductivity Detector (TCD)
RANGE :
Ppm to % (application dependant)
ACCURACY :
Better than ± 1% of range used
STANDARD FEATURES :
Manual or autoranging (user selectable)
Microprocessor controlled
5.6'' TFT intelligent LCD module with Touch Screen
Self diagnosis system with auto-resolve alarm
LAN/Web control
4-20 mA isolated output
Alarm Historic
Digital ouputs for remote monitoring: (all dry relay contacts)
System status (1 output)
Range in use (3 output)
Calibration in use (1 output)
