Rated Voltage (V) - DC24±10% - DC24±10% - DC24±10% - DC24±10% - DC24±10%
Rated Current (A) - 2~5.5 - 2~5.5 - 2~5.5 - 2~5.5 - 2~5.5
I/O Control - 1) Optocoupler isolation
2) 4 input and 4 output terminals (The number of Input and output terminals is varied from different controller models.)
3) Supports PNP、NPN
Max.500KPPS(5V)
LED Display - Red, Yellow and Green Status Lights - Red, Yellow and Green Status Lights - Red, Yellow and Green Status Lights - Red, Yellow and Green Status Lights - Red, Yellow and Green Status Lights
Model Length (m) - Standard 3/5 - Standard 3/5 - Standard 3/5 - Standard 3/5 - Standard 3/5
Usage Environment - 1) Environment Temperature for Use:0-40°C .
2) Environment Humidity for Use: 85% RH or below ( no condensation).
3) Working Environment: avoiding to work under environment with strong light source, strong ultraviolet or corrosive gas.
4) Environment Temperature for Preservation: -10°C to 65°C .
5) Environment Humidity for Preservation: 90% RH or below ( no condensation) .
Dimensions (mm) - 190*36*81.9 - 190*36*81.9 - 190*36*81.9 - 190*36*81.9 - 190*36*81.9
Weight (kg) - 0.331 - 0.331 - 0.331 - 0.331 - 0.331
Cool Down - Natural Convection Cooling - Natural Convection Cooling - Natural Convection Cooling - Natural Convection Cooling - Natural Convection Cooling
