Magnetic vibration sensor SV42

2-wireindustrialcompact

The Vibration Sensor Model compact and robust SV42 has electrical connection with climped cable. The climped cable makes the electric connection safe and practical. The sensor measures the mechanical vibration speed in a range of 10, 20, 30, 40 and 50 mm/s rms on non-rotating surface and converts it to signal 4…20mA (2-wire) proportional with great precision and stability even when applied to large equipment . The SV42 can be installed with a threaded fixed base or magnetic base (recommended when you need to remove or easily move the sensor). Application: Identify Imbalance in industrial equipments Supply: 12...30 Vdc Consumption: max. 22mA Output: 4...20mA (2 wires) Isolation: 500Vrms between circuit and housing Acurracy / Stability: error 0.5% Range: 10, 20, 30, 40 e 50mm/s RMS Electrical Connections: M12 Connector or Cable in Poliethene Body Material: 316 SS Operation Temperature: -10...70°C Class Protection: IP67
