Dielectric mirror TS-08 series

squarerectangularfront-surface

Product overview
Aluminized surface mirrors feature an aluminum reflective coating applied to one side to reflect images and light. Two standard protective overcoats are offered: SiO and MgF2. Compared with MgF2, SiO absorbs in the ultraviolet region and has slightly lower reflectance, but it can be deposited at lower temperature and is more cost-effective. Custom materials, coatings and dimensions are available on request.

Application

• Laser beam steering / optical declination
• Relay mirrors in imaging and shooting system optical paths

Specifications

• Material: B270 / Float glass
• Refractive index (Nd): 1.5230
• Refractive index (Ne): 1.5251
• Chamfering: All circumferences or ridge lines chamfered
• Design wavelength: 400–700 nm

Tolerance

• Diameter tolerances: Round +0 / -0.2 mm; Square 5×5–10×10 +0 / -0.2 mm; Square 30×30–100×100 +0 / -0.3 mm
• Thickness tolerance: ±0.2 mm
• Parallelism: Within 3 minutes (3')
• Plate surface accuracy: 3λ–λ/2 (effective range: within 85% including center)
• Reflection rate (AL+SiO): Around 85%
• Reflection rate (AL+MgF2): Around 90%
• Surface quality: MIL60-40

Lineup

• TS-0811R — 5×5 mm — AL+SiO — Float
• TS-0812R — 10×10 mm — AL+SiO — Float
• TS-0813R — 30×30 mm — AL+SiO — B270
• TS-0814R — 50×50 mm — AL+SiO — Float
• TS-0815R — 100×100 mm — AL+SiO — Float
• TS-0830R — Dia.7 — AL+SiO — B270
• TS-0831R — Dia.10 — AL+SiO — B270
• TS-0832R — Dia.20 — AL+SiO — B270
• TS-0833R — Dia.22 — AL+SiO — B270
• TS-0834R — Dia.26 — AL+SiO — B270
• TS-0835R — Dia.30 — AL+SiO — B270
• TS-0836R — Dia.36 — AL+SiO — B270
• TS-0837R — Dia.40 — AL+SiO — B270
• TS-0838R — Dia.50 — AL+SiO — B270
• TS-0840R — Dia.76 — AL+SiO — B270
• TS-0847R — 30×30 mm — AL+MgF2 — B270
• TS-0848R — 50×50 mm — AL+MgF2 — B270
• TS-0849R — 100×100 mm — AL+MgF2 — B270
• TS-0850R — 52.5×34 mm — AL+MgF2 — B270
• TS-0851R — 72.3×46 mm — AL+MgF2 — B270
• TS-0852R — 89.3×58 mm — AL+MgF2 — B270

Technical characteristics

• Material: B270 or Float glass
• Refractive Index (Nd): 1.5230; (Ne): 1.5251
• Chamfering: All circumferences or ridge lines chamfered
• Design wavelength: 400–700 nm
• Maximum lead time (if out of stock): 45 days
• Note: Surface quality after coating is not guaranteed
