Electric shrink tunnel
Add to favorites
Compare this product
Characteristics
- Type
- electric
Description
Is equipped with a mounting adjustable in height for whatever bottling line. Caps shrinkage adjustable by means of a thermostat. Thermal insulation at high resistance about 1000°centigrades.
In order to obtain a first-rate efficiency: use capsules with perforate heads. Use bottle with a perfectly dry neck. The FORNO TUNNEL is equipped with adjustable feet allowing a quick leveling.
Technical features
Output speed: BMG1 2.000 b/h
BMG2 5.000 b/h
BMG1.2 8.000 b/h
BMG3 12.000 b/h
Caps: max length 80 mm - max. diameter 40 mm
Bottles height: from 150 to 360 mm
Voltage: 220-380 V. single-phase or three-phases by request
Pneumatic lifting device in case of line stop
Compressed air: 25 liters/min. (5ATM)
Catalogs
No catalogs are available for this product.
See all of Tosa‘s catalogs
