Mini PCI Express CPU board i.MX8M Plus Dev Kit – Hailo

NXP i.MX8MARM® Cortex A53compact

Unleash the full potential of the NXP i.MX8M Plus, featuring ARM® Cortex®-A53 processor and Neural Processing Unit (NPU). This empowers Artificial Intelligence (AI) and Machine Learning (ML) capabilities, enhances multimedia performance, supports cutting-edge Edge Computing, provides robust video graphics, and enables rapid processing – all within a compact, cost-efficient, and power-efficient package. VEST software board support package contains drivers for Hailo-8R™ AI accelerator (13 TOPs) and Leopard Imaging 8.4 Megapixels LI-IMX715-MIPI Camera, allowing optional upgrade possibilities. Specifications i.MX8M Plus | 4x Cortex®-A53 @ 1.8GHz, Cortex®-M7 @ 800MHz 16 GLOPS (high-precision) OpenGL® ES 3.1/3.0, Vulkan®, Open CL™ 1.2 FP, Open VG™ 1.1 Neural Processing Unit (NPU) Operating at up to 2.3 TOPS Support Hailo AI Accelerator module up to 13 TOPs (Optional Upgrade) 2GB 32-bit LPDDR4 up to 4.0GT/s 8GB eMMC5.1 Yocto Linux, Ubuntu and Android HailoRT, LI-IMX715-MIPI Camera (Leopard Imaging) 1080p60, H.265/4 1080p60, H.265/4, VP9, VP8 Cadence® Tensilica® Hifi 4 DSP @ 800MHz 2x MIPI CSI with Dual Image Signal Processors MIPI-DSI, up to UWHD and WUXGA | HDMI 2.0a Tx, up to 4kp30 LVDS (4/8-lane) Tx, up to 1920x1080p60 On Board Dual Band Wi-Fi/Bluetooth Module (optional) 2x 10/100/1000 BaseT RJ45 Ethernet, 1x Ethernet with TSN Support USB 3.0 OTG, Type C | 3x USB 3.0 Host, Type A RS485 (Default) or RS232 | 2x CAN/CAN-FD 2mm Pitch 3 Pin Header 2x Debug-UART Header, 2.54mm pitch 5pin header | JTAG-1.27 mm Pitch 2 x 5 Pin Header 12-24VDC, 2.0mm DC Jack or 2 Pin 4.2mm Pitch Mini Fit JR Header 180 mm x 112 mm (Carrier Board) , 69.6mm x 40mm (SOM)
