Conventional lathe E175
horizontal2-axisfor large parts

Conventional lathe - E175 - WEILER Werkzeugmaschinen - horizontal / 2-axis / for large parts
Conventional lathe - E175 - WEILER Werkzeugmaschinen - horizontal / 2-axis / for large parts
Conventional lathe - E175 - WEILER Werkzeugmaschinen - horizontal / 2-axis / for large parts - image - 2
Add to favorites
Compare this product

Characteristics

Control type
conventional
Spindle orientation
horizontal
Number of axes
2-axis
Applications
for large parts
Performance
high-precision, powerful, high-productivity
Associated function
milling machine
Diameter

1,750 mm
(68.9 in)

Spindle speed

1 rpm, 900 rpm, 1,300 rpm, 1,500 rpm, 1,700 rpm
(6.283 rad.min-1, 5,654.867 rad.min-1, 8,168.141 rad.min-1, 9,424.778 rad.min-1, 10,681.415 rad.min-1)

Rapids on X

5,000 mm/min
(3 in/s)

Rapids on Z

10,000 mm/min
(7 in/s)

Weight

18,000 kg
(39,683 lb)

Description

The top end of the range of WEILER E-Series precision lathes. Powerful and energy-efficient with optimum accessibility. The machine for large-size workpieces in high productivity applications with a high chip removal rate for turning lengths up to 15 metres and spindle bores up to 450 mm. A smart range of optional features ensure a high level of efficiency for turning through to milling operations. Precise and universally usable, it impresses through: State-of-the-art control and drive technology Straight-forward operating and programming Extreme accuracy Durability User-friendly ergonomics and an extensive range of accessories. Display unit with 15“ TFT screen Ingenious, user-friendly WEILER graphical user interface Operating panel with handwheels moves with the bed slide to enable precise manual machining “e-TIM” energy conservation system minimizes power consumption Machine accuracy to DIN 860
