Optical preamplifier ATA-5420for detectionultra-low-noisevoltage output
Add to favorites
Compare this product
Characteristics
- Type
- optical
- Other characteristics
- ultra-low-noise, bandwidth, for detection, benchtop, voltage output
- Voltage
2 V
- Frequency
Max.: 20 kHz
Min.: 1 kHz
Description
ATA-5420 Preamplifier
l Bandwidth (-3dB): 1kHz~20MHz
l Maximum Output Voltage: 2Vp-p
l Voltage Gain: 60dB
INTRODUCTION
The ATA-5420 is a preamplifier designed for detecting extremely small signals. It features ultra-low noise power supply and provides a voltage gain of 60dB.
INPUT
The input uses an SMA connector with an input impedance of 50Ω.
OUTPUT
The output uses an SMA connector with an output impedance of 50Ω and a maximum output voltage of 2Vp-p (50Ω).
VOLTAGE GAIN
Voltage Gain: 60dB
APPLICATIONS
Detection of infrared sensors
Detection of weak magnetic field sensors
Optical detection with phototransistors
l Bandwidth (-3dB): 1kHz~20MHz
l Maximum Output Voltage: 2Vp-p
l Voltage Gain: 60dB
INTRODUCTION
The ATA-5420 is a preamplifier designed for detecting extremely small signals. It features ultra-low noise power supply and provides a voltage gain of 60dB.
INPUT
The input uses an SMA connector with an input impedance of 50Ω.
OUTPUT
The output uses an SMA connector with an output impedance of 50Ω and a maximum output voltage of 2Vp-p (50Ω).
VOLTAGE GAIN
Voltage Gain: 60dB
APPLICATIONS
Detection of infrared sensors
Detection of weak magnetic field sensors
Optical detection with phototransistors
