Miter saw CK 412

horizontalfor PVCglazing bead

CK 412 is an automatically operating cutting machine designed for 45 ° cutting of PVC glazing bead profiles. STANDART ACCESORIES KN 152 roller conveyor with manual measuring unit Air gun OPTIONAL ACCESSORIES Electrical foot pedal and regulator & monometer for the vertical clamps SKN 301 length stop together with 1.5 m of digital measuring unit SKN 301 length stop together with 3.0 m of digital measuring unit MKN 300 length stop SKN 300 length stop SKN 600 length stop Digital measuring rod 1.5 m (for SKN 300 & SKN 600 application) Digital measuring rod 3.0 m (for SKN 300 & SKN 600 application) Moulds for special glazing beads KN 152 roller conveyor for outfeeding GENERAL FEATURES Pneumatic saw feed by pushing button Equipped with 2x pneumatic vertical clamps Adjustable saw blade feeding speed Ability to cut 8 different glazing bead profiles without a mould by using mechanical memory Automatic return to start point of the process Twin blade design
