Main spec.
● Working height:5.90m
● S.W.L:240kg
Important features
● battery drive,lower noise,non-pollution
● turning radius is 0 suitable for narrow space working
● automatic display of falut code for easy maintanence
Size
Working Height A 5.90m
Platform Floor Height B 3.90m
Overall Length(With ladder/Without ladder C) 1.44m/1.29m
Overall Width D 0.76m
Overall Height(Rails Up) E 1.95m
Overall Height(Rails Down) 1.55m
Platform Size F 1.28m×0.70m
Wheelbase 1.10m
Performance
S.W.L 240kg
Max. Occupants 1
Ground Clearance 0.06m
Up/Down Speed 30/29sec
Tyre 6in
Power
Lifting Motor 12VDC/0.8kW
Betteries 12V/85Ah
Integrated Charger 12V/15A
