Multi-parameter testing machine HTM series

tensileshearingmaterials

High frequency testing machine HTM Industries • - Plastics • - Metals • - Automotive • - Composites Test load • - 25 kN - 160 kN • - 12 m/s - 20 m/s Type of test • - High-speed tensile tests • - Puncture tests Standards • - ISO 6603-2 • - ASTM D3763-02 • - ISO26203-2 • - SEP 1230 • - ESIS P7-00 Crash Simulation with ZwickRoell The fracture behavior of many materials is dependent on, among other things, the loading rate. Relevant data and constitutive equations are required for the numerical calculation of crash safety. The HTM series of servohydraulic high-speed testing machines allow strain-rate-dependent characteristic values to be determined over a wide speed range. Uses for machine include puncture tests and high-speed tensile tests, as well as peel, and shear tests at high speeds. Tests on components can also be performed in conjunction with the optional T-slotted platform. High-speed testing machines form a complete system with all components - including the hydraulic power pack, test frame with high-speed testing actuator and safety housing, fast measurement and control electronics with PC and evaluation software—matched and integrated.
