ABB switchgear

Current: 3,150 A - 4,000 A
VAC: 145 kV - 170 kV

The gas-insulated switchgear ELK-04 is the ideal solution for reliable energy supply up to a rated voltage of 170 kV, a rated normal current up to 4000 A, and a rated short circuit current up to 63 kA. Based on a few ...

Current: 5,000, 6,300 A
VAC: 420, 550 kV

High performance ratings in a compact design The gas-insulated switchgear ELK-3 for ratings up to 550 kV, 6300 A, 80 kA is applied in all 420 kV and 550 kV grids worldwide. More than 1,500 installed circuit breaker bays ...

Current: 3,150 A
VAC: 245, 253 kV

Eco-efficient and compact solution Gas-insulated switchgear ELK-14 C is the new generation for 245 kV designed to reduce complexity, life cycle costs and environmental impact. The compact design fits any installation ...

Current: 3,150 A
VAC: 72.5 kV - 100 kV

Compact switchgear fully assembled and high-voltage tested in factory, for rapid energizing in 12 hours PASS M00 belongs to Hitachi ABB Power Grids innovative high-voltage hybrid switchgear family ...

Current: 3,150 A
VAC: 145 kV - 170 kV

Compact switchgear fully assembled and high-voltage tested in factory, for rapid energizing in 16 hours PASS M0 belongs to ABB’s innovative high-voltage hybrid switchgear family PASS (Plug and Switch ...

Current: 4,000 A
VAC: 245 kV

Compact switchgear fully assembled and high-voltage tested in factory, for energizing in 20 hours PASS M0S belongs to ABB’s innovative high-voltage hybrid switchgear family PASS (Plug and Switch System). ...

Current: 5,000 A
VAC: 420 kV

Compact switchgear assembled and high-voltage tested in factory, for rapid energizing in 24 hours PASS M0S belongs to the innovative high-voltage hybrid switchgear family PASS (Plug and Switch System). ...

Current: 3,150, 4,000 A
VAC: 72.5, 145, 170, 245 kV

Compact switchgear assembled and high-voltage tested switchyard for rapid installation and energization PASS M0H belongs to Hitachi ABB Power Grids innovative high-voltage hybrid switchgear family PASS ...

Current: 3,150, 4,000 A
VAC: 145, 170 kV

Modular solution for reliable energy supply The gas-insulated switchgear ELK-04 is the ideal solution for reliable energy supply up to a rated voltage of 170 kV, a rated normal current up to 4000 A, and a rated short ...

Current: 2,500, 3,150 A
VAC: 72.5, 145, 170 kV

Gas-insulated switchgear single-phase encapsulated ideal for both indoor and outdoor applications BLF/PASS is the fully-encapsulated evolution of the innovative modular switchgear PASS. BLF/PASS keeps ...

Current: 6,300 A

System pro E power is the innovative ABB’s main distribution switchboard solution with rated current up to 6300A and short-circuit current up to 120kA. Designed to easily fulfill all electrical installation requirements in terms of protection ...

MNS is ABB's low voltage switchgear and controlgear assembly for power distribution and motor control. The MNS design is verified in accordance with the IEC 61439 series and IEC 61641 standards. MNS is of a modular design, ...

MNS provides solutions for intelligent switchgear systems across a broad spectrum. Intelligent systems use standalone protection and control relays engineered into the switchgear modules, in lieu of traditional ...

MNS intelligent type tested switchgear and motor control assemblies use standalone protection and control relays engineered into the switchgear modules, in lieu of traditional overcurrent protection devices. The ...

Current: 6,300 A

With power cables in the back of the switchgear and the possibility install two air circuit breakers in the same panel without any derating, the MNS R layout significantly reduces the width of the switchgear. To ...

... can also be offered based on condition monitoring so that the plant electrical staff can operate the switchgear with ease and can maintain the switchgear in top condition- tackling the day to day situation ...
