PNR liquid nozzles

... connect nozzles. Special tipped nozzles such as ruby and cermet are also available. NOZZLE SPRAY OPTIONS Flat fan spray Solid jet stream Hollow cone Full cone

Orifice diameter: 0.25 in
Flow: 1.8 us gal/h - 6.9 us gal/h
Pressure: 0.4 bar - 4.8 bar

EXAIR's 1/4 FNPT No Drip internal mix deflected flat fan pattern nozzles conserve expensive liquids and protect product finishes from drips by shutting off the liquid flow when no air ...

Orifice diameter: 0.25 in
Flow: 6.9 us gal/min
Pressure: 0.7, 0.8, 0.4, 0.6 bar

... flat fan pattern nozzles are designed for use where space is at a premium. The flat fan pattern sprays at a right angle to the nozzle’s orientation, allowing spray to be placed precisely where it’s needed ...

Media temperature: 426 °C

Model AN8010SS Internal Mix Narrow Angle Round Atomizing Nozzle EXAIR’s Atomizing Spray Nozzles create a fine liquid mist perfect for washing, coating, cooling, dust control and more. ...

Orifice diameter: 0.7 mm - 3.42 mm
Flow: 1.52 l/min - 191 l/min
Pressure: 20 bar - 200 bar

F FLAT FAN NOZZLE – HIGH PRESSURE WASHING F flat fan nozzle is designed for high-pressure washing applications. Their specially designed inner profile allows for even jet distribution, which results ...

Orifice diameter: 2 mm - 10 mm
Flow: 0.3 l/min - 222.7 l/min
Pressure: 0.5 bar - 10 bar

GA FLAT FAN NOZZLE – SHORT BODY The special short body design of the GA flat fan nozzle makes it possible to use nozzle spray pipes in such machines or systems where the available ...

Orifice diameter: 0.4 mm - 6 mm
Flow: 0.9 l/min - 155 l/min
Pressure: 3 bar - 20 bar

GE FLAT FAN NOZZLE – DISC NOZZLE In GE flat fan nozzle (thickness 1.2 mm), the spray jet is close to the turbulence structure and this special design makes them very easy to clean. ...

Orifice diameter: 20 µm - 60 µm

... directed. The liquid stream is entrained by high velocity compressed air to create a range of micron-level spray droplets, resulting in greater surface coverage than conventional nozzles. With this more ...

Orifice diameter: 20 µm - 200 µm

... directed. The liquid stream is entrained by high velocity compressed air to create a range of micron-level spray droplets, resulting in greater surface coverage than conventional nozzles. With this more ...

Orifice diameter: 60 µm - 200 µm

... directed. The liquid stream is entrained by high velocity compressed air to create a range of micron-level spray droplets, resulting in greater surface coverage than conventional nozzles. With this more ...

Orifice diameter: 0.25, 0.34, 0.13, 0.19 in
Pressure: 0 psi - 200 psi
Media temperature: 0 °C - 371 °C

... with most normal fuels, Spin Jets produce a 70° cone angle spray with differential pressure in the 50-200 psi range. With liquids having a surface tension in the 0.002-0.005lb/ft. range, the droplet size is typically ...

Orifice diameter: 0.07 mm
Pressure: 10 psi - 200 psi
Media temperature: 200 °F

Dispensing nozzles are designed for low volume dispensing, ranging from nanoliter droplets to precise dosing of milliliters at a time. These dispensing nozzles are available with orifice sizes as small ...

... a material's height are detected and the nozzle automatically makes the required height adjustments, maintaining the necessary nozzle standoff to avoid collision with warped surfaces and protecting the ...

Orifice diameter: 0.01 in - 0.02 in

... The OMAX Vacuum Assist eliminates delay between water and garnet feed, allowing for consistent automatic piercing of composites, laminates, and other materials. • Available in a wide range of nozzle ...

... SideGate Inline option. It is perfect for part spacing as low as 18 mm, and it is available with individual tip temperature control (up to four tip nozzles) for industry-leading balanced ...

Orifice diameter: 49 mm
Flow: 60.8 l/min
Pressure: 500 bar

... of the flat jet. Applications with hot water up to 100°C can be carried out at any time. Orbimaster nozzles can be connected to the standard 9/16" nozzle pipe of the WOMA guns without adapter. rotor ...

Orifice diameter: 40 mm
Flow: 42.9 l/min
Pressure: 800 bar

... of the flat jet. Applications with hot water up to 100°C can be carried out at any time. Orbimaster nozzles can be connected to the standard 9/16" nozzle pipe of the WOMA guns without adapter. Weight ...

Orifice diameter: 40 mm
Flow: 180 l/min
Pressure: 1,500 bar

... of the flat jet. Applications with hot water up to 100°C can be carried out at any time. Orbimaster nozzles can be connected to the standard 9/16" nozzle pipe of the WOMA guns without adapter. Weight ...

Orifice diameter: 0.01 in - 0.02 in

... sprayed. Due to the small dimension of the carbide insert, this component can be integrated in many different kinds of nozzle/tip bodies. Designed for applications on rotating surfaces, e.g. can coating, drum covers, ...

Pressure: 3 bar - 8 bar
Media temperature: -25 °C - 80 °C

... for use in even the tightest spaces. How it works: The fluid hose is either laid into a pressure-free tank or connected. The atomizer should always be fixed a little above the maximum fluid level ...

Pressure: 2 bar - 8 bar
Media temperature: -25 °C - 80 °C

... Measuring example for fluid volume, 1 min. at 20 °C: ISOVG150: 24 ml at 6 bar; 18 ml at 3 bar Water: 370 ml at 6 bar; 250 ml at 3 bar Matching accessories (please order separately): Pneumatic hose: S-PU4 Fluid ...

Pressure: 5 bar - 8 bar
Media temperature: -25 °C - 80 °C

... oil is applied simultaneously. The minimal-atomizer ZMIN has a built-in fluid shut-off valve. It only switches to flow when compressed air is actually available and blocks the fluid infeed immediately ...

Orifice diameter: 19 mm
Flow: 45 l/min
Pressure: 5 bar

AdBlue/DEF nozzles with stainless steel and thermoplastic versions available. Depending on the model they can be manual or automatic, with spike or thread connection.

Flow: 70, 110, 190 l/min
Pressure: 2, 3, 1 bar
Media temperature: 0 °C - 50 °C

Rotary Nozzle with AC Static Eliminator for Dust Removal and Ionisation • Wide area covarage by rotating the nozzle with high speed • Tungsten pins for extreme high lifetime • Cleaning areas by using ...

Flow: 100 l/min - 110 l/min
Pressure: 4 bar
Media temperature: 0 °C - 50 °C

Rotary Nozzle with AC Static Eliminator for Dust Removal and Ionisation • Wide area covarage by rotating the nozzle with high speed • Tungsten pins for extreme high lifetime • Cleaning areas by using ...

Flow: 215, 290, 375 l/min
Pressure: 4, 6, 8 bar
Media temperature: 0 °C - 50 °C

Rotary Nozzle with AC Static Eliminator for Dust Removal and Ionisation • Wide area covarage by rotating the nozzle with high speed • Tungsten pins for extreme high lifetime • Cleaning areas by using ...

... kHz, the liquid is sprayed when coming into contact with a vibrating surface. • Within the frequency range above 100 kHz, an ultrasonic emitter is placed on the bottom of a volume of liquid. The sound ...

Orifice diameter: 0.2 mm - 1.6 mm

Low Flow Rate Fine Fog Nozzles/ Flat Spray BIMV series Features • Flat spray pneumatic nozzle producing fine atomization with a mean droplet diameter of 100 μm or less (*3). • Features large turn-down ...

Lance Nozzle, good for complete evaporation in cooling tower, large volume is also effective for dust suppression. Features • Pneumatic spray nozzle producing fine atomization with a mean droplet ...

Orifice diameter: 0.2 mm - 5.8 mm

Standard Flat Spray Nozzles - One-piece Structure with Ceramic Tip Even Spray Distribution Features • Flat spray pattern with uniform distribution throughout pattern area. • Even spray impact across ...

... manufactured by ACF®, is a blast nozzle that functions as a normal and dust free blasting that is adapted in all of the different types of blasters that is equipped with a nozzle holder. In addition, ...

Orifice diameter: 0.5 mm - 3.5 mm
Flow: 50 l/min - 5,000 l/min
Pressure: 40 bar - 350 bar

... loss through the nozzle. - Smaller and lighter compact design which is more durable, easy to clean and can be rapidly stripped down and reassembled. - No wrenches or tools are required to install the nozzle. - ...

SPRAY CHARACTERISTICS Fine atomisation of many liquids that cannot be atomised by hydraulic pressure alone. Uniform solid cone. Spray angle varies with air pressure and flow. Separate metering device, such ...

... pressure-fed external mix flat fan spray nozzle The external mix feature allows control of the atomization without changing liquid flow. The lighter the air pressure, the higher the atomization for a ...

Orifice diameter: 1 in
Flow: 25 l/min - 250 l/min
Pressure: 6 bar

... pattern called RYLSTATIC®. RYLSTATIC® is a system that gives you a uniform water fog with smaller water droplets and less friction loss than other traditional systems. VIPER ATTACK nozzles ...

Orifice diameter: 0.5 in
Flow: 25 l/min - 950 l/min
Pressure: 6 bar

... - lled RYLSTATIC®. RYLSTATIC® is a system that gives you a uniform water fog with smaller water droplets and less friction loss than other traditional systems. VIPER BLUE DEVIL nozzles ...

Orifice diameter: 2, 1, 1.5, 2.5 in
Flow: 19 l/min - 1,000 l/min
Pressure: 6 bar

... for a quality fog pattern. Foam: The VIPER® SG nozzle can be used as an aspirating foam nozzle with the addition of inline eductors and foam tubes. Inlet Options: The VIPER® SG selectable flow nozzles ...

Orifice diameter: 1 mm - 8 mm

Standard flat spray nozzles SC Standard flat spray nozzle in cap system MULTIJET. Advantages „„Color coding in accordance with ISO Standard 10625 „„Inexpensive flat spray nozzle Nozzle ...

... fulfills all aspects of explosion protection. The nozzle materials of the IntenseClean 5TM also comply with the EU1935/2004 regulation as well as FDA standards, making the rotating cleaning nozzle ...

Orifice diameter: 40 mm - 80 mm

Off center nozzle with wide throw width characteristic. Advantages Laterally offset orifice Asymmetrical flat spray nozzle Spraying range 6 – 8 m

Orifice diameter: 3 mm - 4.4 mm

The Coolant Spray Nozzle could easily adjust its direction and spray precisely. When the coolants correspond with three pressures-low, medium and high pressures, it can precisely aim at workpiece. They are suitable for ...

Media temperature: 450, 350, 320 °C

Heating nozzles for injection machines and molds, hot melt application, similar spray gun, especially in cases where they are available for mounting in limited areas DESCRIPTION: • Power dissipation: up to 5.5 W / ...

Media temperature: 350, 450 °C

Electrical resistance brass injection nozzle, injection nozzles. Nozzle band heater brass tube Diameter = 30mm Height = 22mm, 25mm, 30mm, 35mm, 40mm, 45mm, 50mm, 55mm, 60mm Cable ...

Orifice diameter: 0.5 in - 1 in
Flow: 80 l/min
Pressure: 3 bar

Nozzle made of polypropylene Housing and internal parts made of polypropylene, valve seat and O-rings made of FKM or EPDM, spring of hastelloy 2.4610, rotatable hose connection. Viscosity: 800 mPas*

Orifice diameter: 0.5 in - 1 in
Flow: 80 l/min
Pressure: 3 bar

Housing and internal parts made of polypropylene, valve seat and O-rings made of FKM or EPDM, spring of Hastelloy 2.4610, rotatable hose connections.

Orifice diameter: 1, 0.75 in
Flow: 100 l/min
Pressure: 2 bar

Housing and internal parts made of white polypropylene, valve seat and O-rings made of NBR, spring made of stainless steel.

 Fine atomisation of many liquids that cannot be atomised by hydraulic pressure alone.  Uniform solid cone. Spray angle varies with air pressure and flow. Separate metering device, such as orifice, metering pump or ...

INDUSTRIAL SPRAY NOZZLES - AIR ATOMISING The AL 30 series produces a wide, round spray pattern with a nominal angle of 70°. This is an internal mix nozzle, where a change in air or liquid ...

Constructed from precision machined and hardened stainless steel, the HP is ideal for high pressure cleaning applications, including car wash and rinse. They provide a high impact spray with an efficient and uniform distribution to reduce ...

Orifice diameter: 26, 32, 38 mm
Media temperature: 470 °C

... extended length and wear protection When using a gate bushing of size ØS = 26 mm, ØS = 32 mm or ØS = 38 mm in conjunction with nozzle types _ET and _HT, we recommend consulting with the engineers. After eroding the ...

Low Velocity Spray Increases Accuracy and Reduces Waste Unlike conventional spray nozzles that rely on high velocity pressure to shear a fluid into small drops, the ultrasonic atomizer uses vibrational ...
