RINGSPANN sleeve couplings

Torque: 10 Nm - 380 Nm

Gear Couplings with continuous sleeve, double engagement gearing Features : - Compensation of axial, radial and angular misalignments - Double engagement allows smooth torque transmission - ...

Torque: 10 Nm - 140 Nm

Cone Clamping Elements Trantorque Mini - metric centres the hub to the shaft for smallest shaft diameters Features - For smallest shaft diameters between 3 mm and 16 mm - Excellent concentricity and transmission of bending moments

Torque: 211 Nm - 658 Nm

Cone Clamping Elements Trantorque OE - metric centres the hub to the shaft for small shaft diameters Features - For small shaft diameters between 17 mm and 35 mm - Excellent concentricity and transmission of bending moments - ...

Torque: 85 Nm - 8,000 Nm
Rotational speed: 1,050 rpm - 4,100 rpm

Flexible Couplings RDA … ESO Flexible Couplings Hub with mounting flange Features Compact design Small dimensions Electrical insulation No stick-slip action Large radial shaft misalignment ...

Torque: 17 Nm - 18,000 Nm

centres the hub to the shaft radial flat height Features Centres the shaft to the hub High transmissible torques Radial flat height is particularly suitable for small hub outer diameters No axial displacement between ...

Torque: 190 Nm - 2,800 Nm

centres the hub to the shaft corrosion protected Features Centres the shaft to the hub All parts 35 µm chemically nickel-coated for high corrosion resistance pursuant to DIN 50021 (neutral salt spray test) High transmissible ...

Torque: 350 Nm - 51,500 Nm

centres the hub to the shaft no axial displacement at short axial width Features Centres the shaft to the hub Short axial width No axial displacement between hub and shaft during clamping procedure due to fixed backstop point

Torque: 38 Nm - 1,050 Nm

centres the hub to the shaft quick assembly, easy to release Features Centres the hub to the shaft Radial flat height is particularly suitable for small hub outer diameters Quick assembly by central groove nut ...

Torque: 74 Nm - 1,500 Nm

centres the hub to the shaft quick assembly Features Centres the hub to the shaft Radial flat height is particularly suitable for small hub outer diameters Quick assembly by central groove nut

Torque: 7.2 Nm - 2,200 Nm

centres the hub to the shaft for small shaft diameters Features Centres the hub to the shaft

Torque: 840 Nm - 141,500 Nm

centres the hub to the shaft highest transmissible torque Features Centres the hub to the shaft Highest transmissible torque For heavy duty applications No axial displacement between hub and shaft during clamping procedure

Torque: 7.3 Nm - 27,393 Nm

for individual clamping connections compact design Features For individual clamping connections Compact design For shaft diameters between 10 mm and 200 mm

Torque: 7,000 Nm - 1,206,000 Nm

centres the hub to the shaft high transmissible torque Features Centres the hub to the shaft High transmissible torque No axial displacement between hub and shaft during clamping procedure

Torque: 300 Nm - 428,500 Nm

easy to detach compact design Features Easy to release Compact design No axial displacement between hub and shaft during clamping procedure Extended tolerances for hub and shaft
