Thomson actuators

Stroke : 50 mm - 1,000 mm
Force: 0 N - 4,000 N
Speed: 3 mm/s

TiMOTION's SR1 series is a low-noise industrial linear actuator specifically designed for applications requiring a resilient and quiet solution. Constructed with plastic helical gearing and sturdy metal housing, the SR1 ...

Stroke : 25 mm - 1,000 mm
Force: 1,000, 2,000, 3,000 N
Speed: 3.5 m/s - 10.8 m/s

TiMOTION's JP6 series in-line linear actuator shares the same design concept as the JP5 and JP7. Specifically designed for use in industrial applications with moderate loads, it’s capable of withstanding loads up to 3,000N. ...

TiMOTION's JP5 is an in-line linear actuator specifically designed for use in low-load industrial applications. With a maximum load capacity of 1,500N, it is particularly suitable for products and applications that require ...

Stroke : 50 mm - 400 mm
Force: 3,500, 7,000 N
Speed: 3.8 m/s - 30.6 m/s

The LA42 actuator offers reliable performance with a push load of up to 7,000 N and a dynamic pull of up to 3,500 N. Its customisable motor housing allows flexible placement, while the IPX6 rating ensures it withstands ...

Stroke : 40 mm - 605 mm
Force: 1,500 N - 8,000 N
Operating Temperature: 5 °C - 40 °C

... healthcare applications, combining power, precision, and adaptability. KA30: Engineered for excellence, the KA30 linear actuator delivers a formidable lifting capacity of up to 8,000 N while maintaining minimal noise ...

Stroke : 40 mm - 605 mm
Force: 0 N - 8,000 N

... healthcare applications, combining power, precision, and adaptability. KA30: Engineered for excellence, the KA30 linear actuator delivers a formidable lifting capacity of up to 8,000 N while maintaining minimal noise ...

Stroke : 50 mm - 1,400 mm
Force: 4,710 N - 11,370 N
Torque: 65 Nm - 600 Nm

The new spindle axis with integrated double guide can be flexibly combined to form 2D and 3D cantilever systems. The double-guide design and the extremely stable connecting elements distinguish the ELGT, make it stable in the system and ...

Stroke : 100 mm - 800 mm
Force: 1,850 N - 15,200 N
Speed: 0.5 m/s - 2 m/s

The heavy-duty, precise spindle axis EGC-BS is quiet in operation and has a unique cross-section that is optimised for maximum rigidity and load bearing capacity. This means you can often use these spindle axes in a smaller size, thus ...

Stroke : 300 mm - 1,500 mm
Force: 650 N - 15,200 N
Torque: 3.5 Nm - 529 Nm

The heavy-duty toothed belt axis EGC-TB has a unique, optimised cross section for maximum rigidity and load bearing capacity. This dynamic linear drive can achieve high speeds even with large loads and long strokes. • Axis for high ...

Stroke : 50 mm
Pressure: 2 bar - 8 bar
Force: 482 N

Cleanline Profile barrel with integrated switches Glandless spool valve for extended life and high performance Adjustable flow regulator for speed control Incorporates Norgren M/50 switches Single air and electrical ...

Torque: 70 Nm - 300 Nm

• 90° rotation. • Single-acting or double-acting operation (SD). • Various mounting accessories available. • Optional magnetic sensors to be mounted with external clamp SWP, or directly in the slot (SD).

Torque: 9 Nm - 174 Nm

• 90° rotation. • Two adjustable rubber stroke end stops. • High lifting torque. • Safety lock, except RBT30. • Optional magnetic sensors.

Stroke : 50, 30 mm
Force: 660 N - 754 N

• Double-acting • Bore: 40mm • Stroke: 30mm or 50mm. • Various mounting accessories. • Optional magnetic sensors. • FDA-H1 food-grade grease.

Torque: 100 Nm
Rotation angle: 35 ° - 300 °

Compact actuator for the operation of final control elements with rotary movement. For continuous positioning, rated torque (80 lbf-ft). The actuator thrust rod transfers the force directly to the final ...

Torque: 250 Nm
Rotation angle: 35 ° - 300 °

Compact actuator for the operation of final control elements with rotary movement. For continuous positioning, rated torque (200 lbf-ft). The actuator thrust rod transfers the force directly to the final ...

Torque: 500 Nm
Rotation angle: 35 ° - 300 °

Compact actuator for the operation of final control elements with rotary movement. For continuous positioning, rated torque (400 / 600 lbf-ft). The actuator thrust rod transfers the force directly to ...

Bore: 32 mm - 125 mm
Pressure: 10 bar
Torque: 4.5 Nm - 300 Nm

Rack-type rotary actuators in various configurations: • Configuration with standard magnet • Version with male pinion or female hole • Mechanical stroke adjustment • Special configurations on request The central ...

Pressure: 1.5 bar - 7 bar
Operating Temperature: -10 °C - 80 °C

... setup of the actuator, start with CLOSE flow microregulators, and open gradually till the achievment of the required speed. Quantity per package: 0 Minimum order quantity: 0 Unit of measure: items Actuators Functional ...

Pressure: 3 bar - 7 bar
Force: 74 N - 560 N
Torque: 0.9 Nm - 22 Nm

Actuator with double rack and play take-up. Angle of rotation adjustable from 0 to 180°. The R3 rotary actuator can come with a mechanical stop or hydraulic end-of-stroke cushioning. There is a version ...

Pressure: 1 bar - 10 bar
Rod diameter: 10, 20, 7, 30, 50 mm
Rotation angle: 0 ° - 190 °

The Series QR rotary actuators are cylinders with a double piston, able to provide high torques while ensuring high stability and a precise rotary movement. The rotation angle can be easily set as desired between 0° and ...

Stroke : 650, 800, 1,000, 1,200 mm
Force: 5,500 N - 32,000,000 N
Speed: 75 mm/s

Ushering in the next evolution of electric actuators, the Thomson Electrak XD is strong enough to take on hydraulic applications while, at the same time, be smarter, smaller and more efficient than competitive ...

Stroke : 450, 100 mm
Force: 2,000, 4,000, 6,000 N
Speed: 54, 15 mm/s

Electrak® LL Linear Actuators Designed for long life, high duty cycle and the ability to work in the harshest environments, these smart electric linear actuators with brushless motors ...

Stroke : 50 mm - 300 mm
Force: 2,000, 500, 250, 1,000 N
Speed: 28, 7, 14.5, 52 mm/s

Designed as a smaller sibling to the Electrak HD actuator, these smart electric linear actuators pack a big punch relative to their compact size and dutifully perform in the harshest ...

These rotary actuators convert linear motion of a piston into a rotary motion via a rack and pinion device, using a double system on 6400 versions. Rotation can be adjusted between 0 and 190 degrees ...

These rotary actuators transform the linear motion of a piston into the rotarymotion of a shaft. The uses in automation are varying and always convenient compareswith other solutions. ROTARY ACTUATORS ...

These rotary actuators convert linear motion of a piston into a rotary motion via a rack and pinion device, using a single pinion-rack system for the 6411 version. The 6410 series actuators ...

Stroke : 25 mm - 100 mm
Force: 0 N - 10,000 N

... available axial actuators or gear box shifting motors. The more robust MX and SMX linear actuator is available, both in an axial or geared version, with a motor and mechanism specially designed for moving ...

Stroke : 30 mm
Force: 40 N
Speed: 40 m/s - 100 m/s

Compact linear actuators with absolute encoder for DC power supply DR series Features Battery-free absolute sensor No external sensors required Compact and lightweight EtherCAT, EtherNet/IP, Profinet, Modbus ...

Torque: 0.9, 50, 9 Nm

Rotary actuators with absolute encoder for AC and DC power supply DGII Series Features - Absolute sensor - High performance, high rigidity - High efficiency, energy saving - EtherCAT, EtherNet/IP, Profinet, ...

Torque: 14, 6, 10 Nm

With a maximum nominal torque of 14 Nm, the new AG24 is a real power pack for format adjustment Stainless steel hollow shaft up to max. ø20 mm, feather key groove at ø14 mm """manual"" traveling without control unit by means of operator ...

Torque: 9, 8, 6, 5 Nm

fieldbus The AG02 actuator is suitable for practically all positioning tasks thanks to its high-power density and robust design. The hollow shaft enables quick and easy installation on the existing adjustment unit, and ...

Torque: 3.2, 1.6 Nm

High-performance compact actuator for complex positioning jobs Space-saving, easy mounting Through hollow shafts up to max. ø14 mm Brushless 50 W, 24 V EC motor with long service life Integrated power and control ...

Stroke : 100 mm - 3,500 mm
Force: 500 N - 900 N
Speed: 0 m/s - 5 m/s

... guideway equipped rodless linear actuator offering high load capacity at a small form factor and high dynamics up to 5m/s and 50 m/s2. The HLR is optimised to build easily multiaxis systems. The HLR is a linear actuator ...

Stroke : 0 mm - 7,000 mm
Force: 50 N - 1,490 N
Speed: 2 m/s - 10 m/s

The OSP-P rodless actuator in bore sizes Ø10 to Ø80mm is a linear actuator, guidance and control package designed into a modular system. Ideally suited for point-to point, reciprocating ...

Stroke : 0 mm - 6,000 mm
Force: 6,000 N - 39,900 N
Torque: 290 Nm - 3,645 Nm

HMRS15 screw driven actuators provide precise path and position control for payloads of up to 8800N. Available with either basic or reinforced profiles, the HMR linear actuators offer user-friendly flexibility ...

Stroke : 300 mm - 5,000 mm
Force: 300 N - 2,000 N
Torque: 0 Nm - 0 Nm

The zip chain actuator has been developed as a linear actuator products using a zip chain. Zip Chain is a chain uniquely developed by Tsubaki. Two chains interlock like a zipper to form a single, strong ...

Stroke : 100 mm - 3,500 mm
Speed: 2,000, 4,000 mm/s

Ball Screw Module, Belt Driven Linear Guide, Positioning Stage, Motion Controller for Cartesian Robot. CE, FCC, RoHS, ISO9001 Certification. Huge Variety of Ready-to-Ship Products Quantity Discounts Starting at 10 pcs custom OEM ...

Stroke : 50 mm - 3,500 mm
Force: 15 kgf
Speed: 4,000 mm/s

... Area】 Laser cutting machine,PV back sheet cutting engraving machine, transportation mechanical arm, assistant device, Electric research test function demonstration, kinds of industrail automatic production line, kinds ...

Stroke : 200 mm - 3,000 mm
Force: 65 N
Torque: 35 Nm - 45 Nm

【Main Feature】 FBL80 linear guide, fully sealed structure, body width 80 mm, it is designed for dust proof usage in hard environment, avoid dust or miscellaneous debris fall into body structure to affect working,large stretch,small compression,hard ...

Stroke : 15 mm - 25 mm
Force: 80 N - 500 N
Torque: 2.4 Nm - 18 Nm

... similar products produced by world's major manufacturers - Round grooves for Ø4 mm magnetic switch Airwork’s rotary actuators of AT series are obtained from a profile in aluminum. The very reduced dimensions and ...

Force: 20 N
Speed: 0.3 mm/s - 100 mm/s

The size 6 [14mm] hybrid linear actuator occupies a mounting footprint of 14mm square but provides over 20N of continuous thrust force. Size 6 hybrid stepper linear actuator has two form factors available ...

Stroke : 20 mm - 150 mm

Based on DINGS' platform products, high precision of lead screw linear actuator and self-developed simple linear module, DLM 20mm series is compact and reliable structure of linear solution. DLM 20mm Series is good precision, ...

Stroke : 20 mm - 250 mm

Based on DINGS' platform products, high precision of lead screw linear actuator and self-developed simple linear module, DLM 28mm series is compact and reliable structure of linear solution. DLM 28mm Series is good precision, ...

Stroke : 75 mm - 400 mm
Force: 2 kN - 30 kN
Speed: 150 mm/s - 500 mm/s

Integrated servo actuator, built-in pressure sensor available Ultra-long lifespan, 10-15 times longer than similar ball screw electric cylinders. High protection level IP65, suitable for harsh working ...

Stroke : 50 mm - 2,500 mm
Rod diameter: 15 mm - 100 mm
Force: 7 kN - 450 kN

... customers’ requirements. Compatible with a wide range of motors. Shock resistance, longer lifespan compared with roller screw actuator. Easy operation in any environment.

Stroke : 40 mm - 2,000 mm
Force: 400 N - 200,000 N
Speed: 4 mm/s - 134 mm/s

... to be able to work in bad industrial environment. Acme Screw Linear Actuator LAP Series (duty cycle 30%) and ball screw Linear Actuator LBP series (100% duty cycle ) Linear actuator ...
