Most design decisions are made up-front in the design process. Typically the first 10% of the product development process affects about 80% of the products total cost. These decisions are made during the initial or concept stage of the development process.
Functional 3D models, created on a Dimension, enable the designer and all others on the design team to make better informed design decisions, resulting in fewer design changes, better product designs, lower production costs and lower product costs. Today companies are turning to low cost 3D Printing systems that deliver quality parts, allowing the designer to iterate designs quickly, testing for form, fit and function.
The Dimension product line features four desktop Printers, the Dimension BST 768 & 1200 (Breakaway Support Technology) and the Dimension SST 768 & 1200 (Soluble Support Technology). All systems are desktop systems, which operate in an office environment. These networked printers are very easy to install and operate. Utilizing the Dimension Catalyst™ software, designers can simply click "print" and their design is sent to the printer. From this point on the Dimension takes over and prints a functional model from ABS plastic. |
|
The First Multi-Material 3-D Printing System
The Connex500™ is the first 3-D printing system that jets multiple model materials simultaneously. It offers the completely unique ability to print parts and assemblies made of multiple model materials, with different mechanical or physical properties, all in a single build. Taking the revolution even further, the Connex500™ can also fabricate Digital Materials™ on the fly, enabling users to create composite materials that have preset combinations of mechanical properties.
Based on Objet’s breakthrough PolyJet Matrix™ Technology, the Connex500 simultaneously prints two FullCure model materials and creates 21 types of Digital Materials. It can also print a single material from any of the original seven FullCure model materials.
By printing with Digital Materials, the Connex500™ allows you to print parts with specific Shore A values to match the values of the intended production materials. This capability opens up new opportunities, bringing you much closer to realizing the final product at an early stage, including feasibility testing and over-molding process simulation.
Parts produced on the Connex500™ have smooth and durable surfaces, with exceptionally fine details and an outstanding surface finish. The high quality output and unique multi-material printing capabilities of the Connex500™ enable you to closely emulate the look, feel and function of an exceptionally wide variety of end products
Key Benefits
- Closer-than-ever simulation of end products
- Wide choice of materials
- Variety of build processes and printing modes
- Outstanding quality, accuracy
- Superb productivity
- Clean, smooth surfaces |
|
Eden350V and Eden350 3-Dimensional Printing Systems utilize Objet's advanced Eden platform, providing the market's most productive, flexible and high-quality way to compress the product design-to-manufacturing cycle.
Eden350V and Eden350 are based on Objet's PolyJet photopolymer jetting technology. PolyJet™ technology enables horizontal layers of just 16m (0.0006"), exceptionally fine details, and ultra-thin walls down to 0.6mm (0.024") depending on geometry.
The systems are designed to provide high-quality, 3-dimensional models quickly and conveniently throughout the CAD/CAM process. With a full 350mm x 350mm x 200mm build size, the new systems offer the flexibility to produce a single large model or multiple smaller models in one build. Eden350V and Eden350 have a similar build size (larger by 10mm) to the highly successful Eden330™, which has been widely adopted across many manufacturing segments.
Key Benefits
- Eden350V delivers superior flexibility & speed
- Full choice of FullCure® materials
- Super-high productivity
- Clean, smooth surfaces |
|
Unlike other 3D Printers, Dimension allows you to test form, fit and function - and as many design iterations you like - right from your desktop.
Dimension 3D Printers generate durable models in ABS plastic. ABS is the most commonly used plastic in manufacturing today. Cell phones, television sets, and the majority of car interiors are made of ABS or ABS blends. ABS allows you to build durable and functional prototypes that can withstand rigorous testing and won't warp, shrink or absorb moisture. ABS models can be drilled, tapped, sanded and painted. ABS is the material of choice by leading manufacturers and is a major reason why Dimension is the fastest selling, office-friendly machine of it's kind. |
|
Nothing communicates design ideas faster than a three-dimensional part or model. With a Dimension 3D Printer, you can bring CAD files and design ideas to life - right from your desktop. Test form, fit and function - and as many design iterations as you like - with functional ABS parts. For added hands-free convenience, consider the Dimension SST with a water soluble support removal system. Starting at $21,900* and €19.350*, Dimension 3D printers represent a major price breakthrough - with leading 3D printing technology.
Simply connect a Dimension 3D printer to your network. Load Catalyst software. Insert the self-loading material cartridges and follow the display panel prompts. That's it. Printing with Dimension BST or SST is as easy as clicking print. See why Dimension 3D Printers are the fastest selling office-friendly machine of its kind - and start shortening your design and development cycle.
Automatic Operation:
Catalyst software automatically imports STL files, orients the part, slices the file, generates support structures (if necessary), and creates a precise deposition path to build your ABS model. Multiple models can be packed within the build envelope to maximize efficiency. |
|
The Eden500V™ 3-Dimensional Printing System is the ideal solution for large-size model requirements or when high productivity is vital. Its build size of up to 500 x 400 x 200mm eliminates the need to glue smaller pieces together for large models and enables simultaneous printing of multiple models on a single build tray - cutting production time for models of all sizes.
Outstanding model surfaces and fine details
- Horizontal layers of 16µ (0.0006”)
- The highest resolution in the market, with identical X&Y resolution of 600 dpi; enables models with fine features in Y direction with no loss of speed
- Eliminates the stair effect common to complicated curved surfaces built in lower resolution
- Produces ultra-fine details usually only available with high-cost systems
- Thin walls down to 0.6mm (0.024”)
Super-high productivity
- Up to 20mm/hour/strip
- Easy switching between High Quality and High Speed printing modes.
- Full weekend unattended operation, using Jumbo materials cartridges (approx. 72 hours of non-stop build capacity)
|
|
With 3D Systems' multi-jet modeling products, you'll iterate designs more quickly, and move to more mature designs in less time and at lower cost than ever before. More mature designs translate to improved product quality, where decisions are made based on feedback from more people involved in the design project - management, co-workers, suppliers and vendors, your toolmaker, customers and clients, and even prospects.
This tool has now become the most efficient manner in which a designer can go from creation to reality. As designers around the world are learning, 3D Systems' products allow them to communicate the way they design - in 3-D.
|
|
| The Z810 System is the fastest and least expensive way to create large appearance prototypes for design review, mock-ups for form and fit testing, and patterns for casting applications. The large build volume allows you to print full-scale concept models for more effective communication with marketing, manufacturing, customers and suppliers. The Z810 System's color capability allows accurate representation of designs including FEA and other engineering data, further enhancing communication. Physical models can be created in plaster or starch-based materials and can be infiltrated to produce parts with a variety of material properties, satisfying a wide spectrum of modeling needs. |
|
With 3D Systems' multi-jet modeling products, you'll iterate designs more quickly, and move to more mature designs in less time and at lower cost than ever before. More mature designs translate to improved product quality, where decisions are made based on feedback from more people involved in the design project management, co-workers, suppliers and vendors, your toolmaker, customers and clients, and even prospects.
The InVision 3-D printer automatically produces robust, superior quality and affordable models for design communication, "form" communication and preliminary assembly analysis applications."
The all new InVision® XT 3-D Modeler provides fast, easy and versatile building of high-definition plastic models and prototypes for concept development, design validation, form and fit analysis, casting or molding patterns.
|
|
The ZPrinter 310 Plus creates physical models directly from digital data in hours instead of days. The ZPrinter 310 Plus is fast, versatile and simple, allowing engineers to produce a range of concept models and functional test parts quickly and inexpensively. The system is ideal for an office environment or educational institution, providing product developers easy access to a 3D Printer. The ZPrinter 310 Plus' sleek design and straightforward user interface make it the ideal entry-level rapid prototyping system. In addition, the versatility of the machine allows users to make parts quickly for early concept evaluation and testing, painted parts for a finished look, or patterns for casting applications.
|
|
| The Spectrum Z510 Full Color System produces high-definition, full-color prototypes quickly and affordably. Superior inkjet printing technology creates parts with crisply defined features, enhanced accuracy, and precise color, so you can print and evaluate physical models of design concepts in their nearly finished state. Rapid 3D printing of high-definition models means you no longer have to wait for prototypes. This unique, 24-bit color, 3D printing capability produces color models that accurately reflect your original design data. Color models communicate more information than any other type of rapid prototype, providing you with a strategic advantage in product development. |
|
