Waste separation at source. This is Engels' basic principle for a better environment. That is why Engels possesses a broad range of waste collection devices. Engels has a solution for house-to-house collection of waste.
Collection baskets
The collection baskets have been especially designed for the collection of paper and glass. The baskets do not take a lot of room and can be stacked. In the meantime, the collection basket has turned out to be popular in offices and schools.
|
|
YOTA AND LAMBDA CONTAINERS
JOTA 40 and JOTA 50 - Stackable baskets made of non-toxic resin, suitable for use with foodstuffs. JOTA 40 also available in a version with a metal trolley.
LAMBDA - Stackable and multiply modular baskets to use in small points of sale. Ideal for the semi-finished pieces used on assembly lines. Accessories: pirouetting wheels and three different spacer elements.
|
|
|
Various sizes and executions of baskets for transportation and distributiuon of food and other goods.
|
|
|
Filters can be manufactured in any shape or size in a wide range of materials to meet individual specifications. We have over 20 years experience working closely with customers to understand their filtration problems and the examples below will provide an understanding of the types of innovative solutions that we have provided.
|
|
|
With the lasting performance of BUTEK washing boxes and carriers enables you to clean and wahs your workpieces with a full integration in the cleaning flow.
|
|
For efficient transportation and intermediate storage. The straight ZARGES baskets can be stacked on top of each other while the tapered baskets can be stacked one inside the other for transporting while empty.
Straight version.
Robust stacking corners permit stacking one on top of the other.
Ergonomic grips in the end faces.
Plastic skid strips.
|
|
Model 6 Basket Strainer and Bag Filters
Model 6 strainer/filter housings are made in 3 sizes and 3 pressure ratings, and can serve as basket strainers (for particle retention down to 74 micron size) or as bag filters (for particle retention down to 1 micron size). In all cases, covers are easily removed without special tools, and the basket or bag is easily cleaned or replaced.
Features
- Low pressure drops
- Permanently piped housings
- Covers are O-ring sealed
- Carbon steel, or stainless steel (304 or 316) construction for housings
- All housings are electropolished to resist adhesion of dirt and scale
- Easy to clean!
- Adjustable-height legs, standard
- O-ring seals: Buna N, EPR, Viton®, Teflon® • ASME code stamp available
- Three pressure ratings: 150, 210 or 300 psi
- Duplex units are available
- Can provide 3.4 square feet of basket or bag surface area without need for ASME code construction
- Three basket depths: 12, 18, or 30 inches (nominal)
- Special alloys
|
|
These high-capacity filters and strainers require no flow interruption for servicing
- For use with filter bags for filtering to as fine as one micron, or with perforated strainer baskets
- From 2 to 10 Model 8 housings are mounted in parallel to inlet and outlet manifolds
- Each unit has inlet and outlet valves, gage ports, and a drain port, to permit servicing one at a time
- These are completely packaged free- standing systems in carbon steel and stainless steel
|
|
PUMP-PROT ECTING BAS KET ST RAINERS
Polypropylene build, no metal parts and low head loss make them ideal for installation on a pump suction port, providing protection from suspended solids, filaments, algae, etc. The strainer can be easily removed by unscrewing the lid without the need for tools.
max. operating pressure 7 bar
For chemical sector, water treatment plants, fish farming, the galvanising, tanning, textile, paper and printing
industries and a host of other applications.
Available in five different connection sizes: 1”, 11/2”, 2”, 21/2”, 3”
|
|
|
Viking Lid-Ease® strainers protect pumps and systems from foreign materials. Available in stainless steel, cast iron, ductile iron and aluminum, all with stainless steel baskets, they are suitable for almost all process fluids. Basket mesh options range from 140 to 4780 micons. Ports range from 0.75- to 8-inch, in tapped, grooved and flanged models. The breech lock lid allows easy basket removal for cleaning, and low pressure drop minimizes impact on pump system NPSHa. Magnetic inserts available for trapping ferrous particles.
|
|
Type "BASKET"
- Body material: Ductile Iron GGG40.3
- PFA/FEP or PVDF-lined
- Temperature Tmax = 423 K (150ºC)
- Exchangeable filter basket
- Low pressure drops
- Flow area corresponds to size of nominal bore
- Filter basket made of PFA/FEP separately available
- 3mm mesh width (other mesh width on request)
- With DURAN tubular sightglass on request
|
|
Simplex Plastic Basket Strainers
1/2" to 8" - PVC, Corzan® CPVC and Eastar®
Duplex Plastic Basket Strainers
1/2" - 4" - PVC, Corzan® CPVC and Eastar®
Duplex Plastic Basket Strainers
6" - 8" - PVC & Corzan® CPVC
Plastic Y-Strainers
1/2" to 4"- PVC - Clear PVC and Corzan® CPVC
Y Strainers - Clear PVC
1/2" to 2"
|
|
Simplex Plastic Basket Strainers
1/2" to 8" - PVC, Corzan® CPVC and Eastar®
Duplex Plastic Basket Strainers
1/2" - 4" - PVC, Corzan® CPVC and Eastar®
Duplex Plastic Basket Strainers
6" - 8" - PVC & Corzan® CPVC
Plastic Y-Strainers
1/2" to 4"- PVC - Clear PVC and Corzan® CPVC
Y Strainers - Clear PVC
1/2" to 2"
|
|
|
|
|
|
690 Marine Bronze Duplex Strainer
Size: 3"
Strainers provide positive and inexpensive protection for costly pumps, meters, valves,
and other similar mechanical equipment by straining foreign matter from the connected piping
system. Installation of a strainer before mechanical equipment can ensure trouble free service
and avoid costly shutdowns for repair or replacement of equipment damaged by foreign
matter. The size of the perforation or mesh in the basket screen will determine the smallest
particles captured. See Strainer Information section of the Mueller Steam Specialty
Engineering binder for detailed information including sizes and materials available.
Typical Service
As with all duplex strainers, these are used where flow cannot be shut down for basket cleaning.
These sight glass duplex strainers are typically used in engine cooling water systems in seawater and heat exchanger applications.
When supplied with fine mesh lined baskets, they can be used to clarify potable water supplies.
Features
Clear acrylic basket chambers allow direct visual inspection of the fluid flow and basket condition.
Flow diversion is accomplished by a single tapered plug diverter that moves 90°, thereby opening one chamber while closing the other.
Sight glass chambers and baskets are accessed for easy cleaning, inspection, and replacement by removal of two wing nuts.
|
|
FEATURES
- Quick open cover
- Straight through flow
design
- Low pressure loss
- Convoluted-basket
design
- Hand removable basket
- Threaded drain
- O-ring cover seal
- Perforated or mesh
stainless steel baskets
standard
OPTIONS
- Basket perforations from
1/32" to 1/2"
- Basket mesh 20 or 40
- Monel baskets
- Vent valves
- Drain valves
- 1/4" NPT taps
- Pressure differential
gauge and switch
connections
|
|
97FB-CI: Cast Iron, Simplex, Basket Strainers
Description:
Series 97FB-CI Cast Iron, Simplex, Basket Strainers feature an angle-designed basket, cast iron body with flanged connections, stainless steel screen, bolted retainer cap (Model 97FB-CIB) or clamped retainer cap (Model 97FB-CIC) and cast-iron blow-off plug. Sizes 8 to 12 in. (200 to 300mm) have a side drain facing outlet of the strainer. Model 97FB-CIB - Maximum Pressure (non-shock): 200psi (14 bar) @ 150°F (66°C) WOG, 125psi (9 bar) @ 353°F (178°C) WSP. Model 97FB-CIC - Maximum Pressure (non-shock): 50psi (3 bar) @ 150°F (66°C) WOG.
|
|
Basket Strainers
Used to filter any fluid in industrial pipes.
The basket strainer is basically used to protect equipment such as:
- Pumps;
- Flow meters;
- Spraying systems;
- Cooling towers and other.
Basket strainers do not require any tool for maintenance. They have a very simple, strong construction. The cover is sealed with an o-ring, which ensures perfect sealing with minimum grip.
This strainer range meets the needs of most industrial segments:
- Chemical;
- Petrochemical;
- Pharmaceutical;
- Food;
- Hydroelectric;
- Thermoelectric;
- Pulp and paper, etc.
|
|
Sprymaster plants are washing booths provided with fixed or rotating internal platform for spray washing with a water-based detergent.
Operation is clean, odourless and fully isolated from the surrounding environment. The spraying chamber is closed by a front door driven by one or two pneumatic cylinder(s) or a motor reducer and racks. The ducts of the spraying nozzle network are oriented in the washing chamber.
The jet configuration has been arranged in such a way as to cover the surface of the items being treated through a procedure which includes chemical, mechanical and thermal functions.
|
|
|
|
|
|
Rosink Cleaner:
Aqueous cleaning of parts!
The Rosink Cleaner is an economic, forward-looking, environmentally friendly, efficient and mobile alternative to solvent cleaning. The system technology of the Rosink Cleaner offers a modular system allowing customization of the highest degree. It is possible to equip the Rosink Cleaner with integrated rinsing programs in single or multi-tub systems followed by drying programs.
Cleaning method
Consisting of 96% water and 4% biodegradable special detergent, the cleansing liquid is automatically heated and controlled by a timer. The
parts to be cleaned are simply put in the rotary basket and
then the pivoting lid is closed and safety locked. A pump
sets the cleansing liquid under pressure and transports it via
special fan nozzles to the parts to be cleaned.
Retrofitting as a rotary drum cleaning machine
It takes only a few seconds to retrofit the Rosink Cleaner as a
rotary drum cleaning machine. Simply hook in the basket receiver into the centring device and insert the unigoods basket with the goods
to be cleaned. The drum equipment is particularly well
suited to the thorough cleaning of hardware, bulk
goods, scooping parts etc. Sensitive parts can be fixed inside the drum. The velocity of the drum depends on the application and is between 1 and 20 rpm.
With a few simple steps a special nozzle holder can be attached, this makes the drum cleaning most effective and efficient.
|
|
Viking Washers :
- Rotary Washers
- Swedebrator Basket Washers
- Tumble Washer - Endless Belt
- Pass Through Washers
- Vibratory Shakers
|
|
The parts to be cleaned are placed into a revolving basket Rapid cleaning is achieved by spraying hot detergent solution from three spray pipes located around the backet.
Spécifications:
Basket diameter : 600 to 1100 mm
Maximum loading : 500 kg
Pump pressure : 2 to 10 bars
Applications:
Cleaning of parts
Cleaning of tools
Surface treatment
Cleaning of parts for reconditioning and renovation.
Degreasing of heavily contaminated parts within a few minutes..
Characteristics:
Enclosed environment
Strong stainless steel construction
Small space required
Short pay back time
Low consumption of detergent and energy
|
|
In complement of our offer of equipment of vibro-abrasion we have a complete range of equipment of washing and cleaning of machine elements which must be implemented for the whole of the scopes of application where the parts must be clean.
Various solutions exist:
- Machines Eco basket
- Washing machines with revolving plate
- Washing machines with passage
- Machines with ultrasounds
|
|
Industrial rotary basket spraying washing machines: Mod. 160
With a basket size of 600mm diameter is the smallest in the range.
Maximum load capacity is of 100 kgs.
The machine is fitted with electric heating, thermostat control and cycle timer.
These models are single tank.
|
|
|
|
|
|
The BRC cleaners are designed to cleanin components placed in a basket. The wash in done by rotating the basket in a bath with hot alkaline cleaning fluid. There is continuous high-pressure injection of cleaning fluid into the bath. This process results in strong cavitation, which is a highly efficient method to clean component corners and holes.
The BRC cleaners are equipped with a rotating fixture that can be oscillated. It is possible to perform 1-4 stages in the same chamber, e.g. wash, rinse, passivation and drying. The re-circulating cleaning liquids are pumped with separate pumps from each tank and continuously filtrated through the filtration units.
These cleaners come highly equipped as standard. Features such as heat and sound insulation, a stainless steel construction, automatic refill, overfill protection, high-pressure vertical multistage pumps and several other kinds of equipment make the cleaner a perfectly functioning unit. Sampo Rosenlew offers accessories for the BRC series, which ensure easier use and prolonged wash fluid life. The cleaning process can be fully automated by integrating a conveyor system to the production line.
|
|
Standard features:
- Oil wheel with collection tank
- Removable chip basket
- Adjustable spray pressure
- NEMA 12 electrical enclosure
- Door safety interlock
- Adjustable wash cycle timer
- Electric immersion heater
Optional features:
- Tank Level Option - features heater protection and automatically maintains liquid level of tank
- Elevated Parts Basket - provides a second tier for increased capacity of parts, protective basket coating available for delicate parts
Specifications:
- Turntable Size: 36" Diameter
- Work Opening: 38" W x 50" H
- Load Height: 32" High
- Overall Size: 55-1/2" W x 85-1/4" H, x 57-1/2" D
- Tank Sizes: 114 Gallons
- Heater Size: 18 KW (1)
- Drive Size: 1/4 HP DC
- Pump Sizes: 5 HP (10 HP opt.)
- Max. AMP Draw: 25A @ 480 Volts
|
|
Washing cabinjet are suitable for spray degreasing with water cleaning solutions of parts lying in a turning baskets: the treatment takes place in an opportune cabinet, locked, using the circulating solutions in the lower tanks.
In order to obtain a complete treatment in any section there are ramps positioned over under and on sides.
Inlet ramps of the solutions to the cabinet are independent among the different phases of washing cycle to avoid unwished bath mixing.
|
|
|
|
|
|
The TORUSMILL® TM is a completely new, patented dispersion system which allows for a particularly economic and environmentally dispersion of high quality products. With the TORUSMILL® a predispersion with a dissolver disc and afterwards the extremely fine grinding with an integrated basket mill can be made in one process technology machine in one container.
This innovation intelligently combines proven high speed dispersion technology with a basket mill system. In operation, the TORUSMILL® is first used to predisperse the product with a dissolver disc. During predispersion the torus shaped basket is "parked" in the upper part of the machine. After predispersion, the milling basket, containing the grinding beads and the milling tool is lowered into the millbase and the fine milling process can begin. The fast circulation of the millbase within the milling basket is generated by the dissolver disc and integrated pump wheel; because of this excellent dispersion results and a very narrow particle size distribution can be achieved very quickly. Due to the fact that no pumps, pipes, valves and additional containers are necessary, the cleaning is very easy and a quick change of the millbase is possible.
|
|
Basket mill TML – easy to clean and quick product change
Basket mills are extremely efficient grinding systems comprising of a grinding basket that is lowered into the millbase for dispersion. During operation the grinding basket stands still while the milling shaft to which the milling tool, dissolver disc and pump wheel are fastened, rotates. The rotating milling tool agitates the beads inside the basket which disperses the millbase. The dissolver disc at the tip of the shaft and the pumping wheel generate effective circulation of the millbase, helping to provide excellent dispersion results in a short period of time. The TML basket milling system includes a special adapter flange which enables it to be fitted to a DISPERMAT® without the need for any tools. If the standard dissolver shaft and the TML basket milling system are frequently interchanged, an additional DL dissolver shaft is recommended.
|
|
|
|
|
|
The TORUSMILL® SK is a dispersion machine with technology which corresponds closely to the TORUSMILL®. Whereas with the TORUMILL® TM the predispersion with a dissolver disc as well as the milling process with an integrated milling system is possible, the TORUSMILL® SK has been modified to disperse exclusively as a basket mill.
The TORUSMILL® SK is a basket mill where the milling basket filled with bead mills is lowered into predispersed millbase. During the operation the milling basket stands still while the shaft on which the pump wheel, the milling tool and the dissolver disc are fixed, is rotating.
By the means of the milling tool the milling beads are moved within the basket mill and the millbase is dispersed. The separation of the beads/millbase is ensured by a sieve in the bottom of the milling basket. The dissolver disc and above all the pump wheel, which is built into the milling basket, ensure exceptional circulation of the mill base and that excellent milling results are achieved very quickly.
|
|
