Carbide cutting insert :

26 industrial products

16 products in		Cutting inserts
8 products in		Milling tools
2 products in		Drill bits, Reamers

Carbide tools

16 products in

Cutting inserts

The Complete Range

Our carefully planned, wide variety of indexable inserts is one of the highlights of the Pokolm-Voha program. A perfect complement to our milling cutter program, it offers a wide selection of carbide grades, geometries, and diverse application possibilities. The program provides an optimal solution for every task:
Diameters of 5 to 20 mm (radii of 2.5 to 10 mm), diverse shapes, carbide grades, and coatings – along with a great variety of milling cutter bodies, our patent-protected insert seats, and arbor systems – allow combinations in every possible way.

All Pokolm-Voha inserts have been developed based on shop-tested applications by our customers, and we improve our inserts to meet every new challenge. This constant and innovative developmental process, and a remarkably intensive cooperation with our carbide suppliers and coating partners, guarantee state-of-the-art types of inserts at all times.

Carbide cutting insert Whizcut

WhizCut offers a complete external and internal range of toolholders and carbide inserts specially developed for swiss automatic lathes. With this new technology WhizCut will help You improve productivity and reduce interruptions in production.

Carbide cutting insert Arno

SHARK-Cut®...the high-performance drilling and turning system –
effective and productive!

• CNC polished inserts ( AWI / WI ), available optionally in coated or non-coated finish
• extremely efficient boring tools
• suitable for turning and boring
• four machining processes possible with one tool
• maximum precision and process dependability
• all holders complete with an internal coolant feed
• drilling depths up to 3xD

Carbide cutting insert CERATIZIT

For machining the desired part, we choose the most favourable manufacturing method. The fastest way of getting blanks is the direct pressing of the granulated powder by a corresponding tool and sintering afterwards. An alternative for complicated or bigger parts is the two step shaping method. Details: maximum possible are blanks up to Ø 190mm or a length of 300mm.

Carbide cutting insert Tungaloy Germany GmbH

T9000

To meet the continuously growing demands of modern tool concepts as to economic efficiency and productivity, Tungaloy designed the new T9000 series. The result of our intensive research and development is a modern cutting grade series, which stands for increased tool life at higher cutting speeds in machining operations of steel. Compared to traditional cutting materials, the new MT-CVD coated substrate has a unique design of each single coating layer. The patented new "Double-Bridge" coating technology stands for extremely increased adhesion of each single layer. Thus thicker coatings can be applied without weakening the adhesion between each single layer. These characteristics grant significantly increased wear resistance, thus allowing for higher cutting conditions.

Carbide cutting insert Sumitomo Electric Carbide

Carbide and Cermet Inserts

Grade Hardness (Hv) T.R.S. (kg/mm2) Applications

T110A 1,680 165 Finish turning of steels and stainless steels
T1200A 1,680 165 General purpose to finish turning of steel
and stainless steels
T2000Z 1,680 165 General purpose to finishing of steels
and stainless steels with ZX Coating
T3000Z 1,680 165 Medium to finish interrupted machining of
steel with ZX coating
T130Z 1,550 200 Turning of steels and stainless steels with
PVD coating

Carbide cutting insert Horizon Carbide Tool

VIDE

Carbide cutting insert Troys industries

VIDE

Carbide cutting insert Ultra Dex

Ultra- dex stocks all the inserts that our bars use
We also offer more the one grade
CDHB CDGW CPGW CCGW
CDGT CPMT CCMT DCMT

Carbide cutting insert Sumitomo Hardmetal Division

Product : Inserts
ISO Cat. No : CNMG120402N-FP
CIS Cat. No : CNMG430FEP
Grade : T130Z (PVD Coated)
Chipbreaker FP type : Fine Finishing(Negative)
Stock: p : Tailor Made

Carbide cutting insert TUNGALOY

T9005
Combines a specially designed deformation-resistant substrate with a new CVD coating mainly composed of a thick alumina layer.
Excels in wear resistance in high-speed light cutting.

T9015
Combines a specially designed deformation and chipping resistant substrate with a new CVD coating mainly composed of a thick alumina layer.
Ensures very good resistance against crater wear and breakage in medium-duty turning.

T9025
Combines a specially designed wear and chipping resistant substrate with a new CVD coating mainly composed of a tough and fine grain columnar TiCN crystals.
Excels in impact and wear resistance in heavy duty turning.

T9035
Combines a specially designed tough hardmetal substrate with a new CVD coating mainly composed of a tough and fine grain columnar TiCN crystals.
Provides superior impact resistance in heavily interrupted turning.

PCBN cutting insert Sumitomo Electric Carbide

Grade Hardness (Hv) T.R.S. (kg/mm2) Applications

BN100 400-4500 80 Turning of gray cast iron and exotic materials
BNX10 2800-3200 80-90 High speed continuous cutting of
hardened steels
BN250 3200-3500 100-110 Continuous to moderately
interrupted cutting of hardened and
cast irons
BNX20 3200-3400 95-110 High speed continuous cutting of
hardened steels (HrC 45-68)
BNX25 3000-3200 100-110 High speed continuous cutting of
hardened steels (HrC 45-68)

PCD cutting insert Sumitomo Electric Carbide

Grade Hardness (Hv) Applications

DA2200 9,000-10,000 Finishing, roughing and interrupted
machining of aluminum and non-ferrous
materials
DA10 10,000-12,000 Machining of aluminum, copper, wood,
rubber, graphite and carbide
DA200 8,000-10,000 Interrupted cutting of non-ferrous alloys and
plastics
DA90 10,000-12,000 High-silicon aluminum alloys, ceramics and
carbide cutting

Cermet cutting insert MITSUBISHI CARBIDE

NX3035

The latest generation of cermet inserts for steel turning now provides cutting edge stability even when using coolant, an area where the use of conventional cermet grades resulted in unpredictable tool life.

A large range of over 300 inserts, with negative and positive geometries are available and the series also includes a varied range of chip breakers to suit all applications.

NX3035 uses a special alloy binder that offers even higher thermal conductivity and bonding strength, and as a result it delivers much improved thermal shock resistance. This reduces thermal cracking and enables NX3035 to exhibit a high degree of tool life stability even during wet machining, an area where conventional cermet lacks performance. Tests have shown that thermal shock resistance was doubled compared to other cermet grades.

The use of coolant during high speed finishing helps to maintain excellent surface finishes and additionally, dimensional accuracy of components can be maintained for longer due to the stability of the cutting edge.

... products without technical information

Carbide cutting insert Applitec Moutier

Carbide cutting insert MICRO 100

... see all the products in the category

Cutting inserts

8 products in

Milling tools

Carbide rotary burr Best Carbide Cutting Tools

VIDE

Miniature carbide router milling cutter Best Carbide Cutting Tools

VIDE

Solid carbide end mill Best Carbide Cutting Tools

VIDE

Balinit coated solid carbide end mill Ingersoll Cutting Tools

Series 46J, 46D, 47J, 47D, 48D Solid Carbide Tip End Mill
45 Degree Helix, Center Cutting, High Precision, Grade IN2005

Diameters:
.312" and .625"
Cutting Edge Length:
.20" and .47"
Cutting Edge Radius:
Sharp, .015", .030", and .060"

Coated solid carbide end mill Ingersoll Cutting Tools

Series 46J, 46D, 47J, 47D, 48D Solid Carbide Tip End Mill
Diameters:.312" and .625"
Cutting Edge Length:.20" and .47"
Cutting Edge Radius:Sharp, .015", .030", and .060"
